Product Name: Digital Output Module
Brand Name: ABB
Model Number: ICSC08L1 FPR3319101R1082
Place of Origin: Sweden
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | ABB ICSC08L1 FPR3319101R1082 Digital Output Module |
| Manufacturer | ABB |
| Product Type | Digital output module |
| Part Number | ICSC08L1 FPR3319101R1082 |
| Estimated shipping dimensions | 12.2x9.5x6.3cm |
| Weight | 0.28 kg |
| Place of shipment | Xiamen, China |
| Country of origin | Sweden |
| Output current | 0.5 A per channel |
| Maximum total output current | 2 A for all 8 outputs |
| Power Supply | 24 VDC power supply required |
| Configurable input delay | 2 ms to 32 ms |
The ABB ICSC08L1 FPR3319101R1082 is a high-performance digital output module designed for industrial automation and process control systems. Manufactured by ABB, the module provides reliable digital signal processing and flexible I/O functionality for demanding industrial environments.
The ICSC08L1 supports eight user-configurable channels that can be used for 24 VDC input signals or 24 VDC digital output signals. Each output channel supports up to 0.5 A current, with a maximum combined output current of 2 A across all eight channels. The module also features short-circuit protection, configurable input delay settings, and stable 24 VDC power operation to ensure reliable system performance.
With its compact design, configurable functionality, and industrial-grade reliability, the ABB ICSC08L1 FPR3319101R1082 is suitable for a wide range of automation applications including PLC systems, DCS systems, factory automation, and process control environments.
The primary function of the ABB ICSC08L1 FPR3319101R1082 is to provide configurable digital input and output signal handling for industrial control systems. The module enables communication between field devices and the automation controller by processing digital signals from sensors, switches, relays, and actuators.
Its configurable channels allow users to define each channel as either an input or an output according to application requirements. The configurable input delay feature helps reduce signal noise and improves input stability in electrically noisy industrial environments.
The module’s output channels are designed to drive external devices such as relays, indicators, solenoids, and contactors while maintaining safe and reliable operation through built-in short-circuit protection.
Typical applications include:
1. What is the ABB ICSC08L1 FPR3319101R1082 used for?
The ABB ICSC08L1 FPR3319101R1082 is used for digital input and output signal processing in industrial automation and control systems.
2. How many channels does the ABB ICSC08L1 FPR3319101R1082 provide?
The ABB ICSC08L1 FPR3319101R1082 provides eight user-configurable channels.
3. What voltage signals are supported by the ABB ICSC08L1 FPR3319101R1082?
The ABB ICSC08L1 FPR3319101R1082 supports 24 VDC digital input and output signals.
4. What is the output current rating of the ABB ICSC08L1 FPR3319101R1082?
The ABB ICSC08L1 FPR3319101R1082 supports up to 0.5 A per channel with a maximum combined output current of 2 A for all eight outputs.
5. Does the ABB ICSC08L1 FPR3319101R1082 include short-circuit protection?
Yes, the ABB ICSC08L1 FPR3319101R1082 includes built-in short-circuit protection for safe and reliable output operation.
