Product Name:Main Processor
Brand Name: TRICONEX
Model Number:3008
Country of Origin:USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
TRICONEX |
Model Number: |
3008 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
Delivery time in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
The TRICONEX 3008 is a Triple Modular Redundant (TMR) Main Processor module serving as the core computing engine for the Tricon v9.6 and later Safety Instrumented Systems (SIS) platform. Each Tricon system requires three TRICONEX 3008 modules installed in parallel within the main chassis, executing user-defined safety logic and performing 2-out-of-3 (2oo3) hardware voting to eliminate single points of failure without interrupting process operations. The 3008 is engineered for high-integrity applications, offering online diagnostics, battery-backed memory retention for up to six months, and seamless integration with TriStation 1131 programming software for SIL 3–rated safety control across oil & gas, power generation, and chemical processing environments.
Emergency Shutdown (ESD) Systems: Executes deterministic safety logic for rapid trip response in refineries, offshore platforms, and LNG terminals
Fire and Gas (F&G) Detection: Processes signals from flame detectors, gas sensors, and manual call points to activate suppression systems and alarms
Burner Management Systems (BMS): Controls ignition sequences, flame monitoring, and fuel valve positioning in boilers and furnaces
Turbomachinery Protection: Monitors vibration, temperature, and pressure on compressors and turbines, initiating protective shutdowns
High-Integrity Pressure Protection Systems (HIPPS): Critical pipeline and midstream safety shutdown applications
Nuclear 1E Safety Systems: Certified for safety-related applications in nuclear power plants
Semiconductor Manufacturing: Environmental, health, and safety applications requiring SEMI S2 compliance
Triple Modular Redundancy (TMR) architecture with 2-out-of-3 (2oo3) hardware voting mechanism
Hot-swappable module replacement without system shutdown or process interruption
Continuous online diagnostics with transient fault masking and persistent fault identification
TriBus high-speed communication at 25 Mbps with 32-bit CRC protection and fully isolated DMA
Battery-backed SRAM for program and retentive data retention during power loss (minimum 6 months)
Precision TriClock timing with battery backup for Sequence of Events (SOE) timestamping
Optically isolated RS-232 diagnostic port (500 VDC isolation) for real-time troubleshooting
Comprehensive front-panel LED indicators: PASS, FAULT, ACTIVE, MAINT1/MAINT2, COM TX/RX, I/O TX/RX
IEC 61508 SIL 3 certified with diagnostic coverage >99%
Wide operating temperature range supporting G3 harsh industrial environments
ATEX Zone 2 and IECEx hazardous location certification
Executes user-written safety control programs developed in TriStation 1131, supporting Function Block Diagram (FBD), Ladder Diagram (LD), Structured Text (ST), and CEMPLE languages
Performs 2-out-of-3 (2oo3) hardware voting on all input and output data via the TriBus backplane to ensure data integrity
Manages comprehensive system and I/O diagnostics, validating fixed-program memory, static RAM, processor instructions, and I/O communication channels
Detects and time-stamps Sequence of Events (SOE) state changes with millisecond precision for post-trip analysis
Synchronizes system-wide time across multiple networked Tricon controllers using Network Communication Modules (NCMs)
Provides fault detection and isolation — persistently faulting modules are automatically identified for replacement by safe removal of the affected module
Manages hot-swappable replacement: a replacement 3008 module can be inserted into an empty slot and granted control after passing diagnostics
Supports remote firmware upgrade and remote diagnostics via TriStation
Q1: How many 3008 modules are required per Tricon system?
A1: Three 3008 modules must be installed in the main chassis, operating in parallel as three independent TMR channels for 2oo3 voting.
Q2: Can 3008 be mixed with older 3006 or 3007 processors?
A2: No. All three Main Processors in the chassis must be the same model and revision for TMR voting to function correctly.
Q3: What happens to the control program during power loss?
A3: The battery-backed 32 KB SRAM retains the control program and retentive variables for a minimum of six months after external power loss.
Q4: Can a faulty 3008 be replaced without shutting down the process?
A4: Yes. The TMR architecture allows hot-swapping — a failed processor can be removed and replaced while the other two maintain active control.
Q5: What is the purpose of the FAULT indicator on 3008 front panel?
A5: The FAULT LED illuminates when a persistent hardware or diagnostic failure is detected on that module, identifying it for hot replacement.
