Product Name: 3300 XL 8 mm Probe
Brand Name: Bently Nevada
Model Number: 330103-00-07-10-12-05
Place of Origin: United States
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
overview
| Product Name | 3300 XL 8 mm Probe |
| Brand Name | Bently Nevada |
| Model Number | 330103-00-07-10-12-05 |
| Place of Origin | USA |
| Warranty | 12 months |
| Payment Methods | T/T |
| Shipment | DHL/UPS/EMS/Fedex... |
The Bently Nevada 330103-00-07-10-12-05 is a 3300 XL 8 mm proximity probe designed for integration with the Bently Nevada 3500 monitoring system. It uses eddy current technology to provide accurate vibration and position measurements in rotating machinery. Engineered for high reliability, it serves as a critical sensing element in condition monitoring systems, ensuring stable and continuous data transmission through FluidLoc cable protection.
Measures shaft vibration and radial position in rotating machinery
Converts mechanical motion into electrical signals using eddy current sensing
Transmits measurement data to 3500 monitoring modules
Supports single or dual-redundant probe configurations
Enables automatic switchover to backup probe in case of primary failure
Provides continuous monitoring for machinery protection systems
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
| Product Name | Bently Nevada 330103-00-07-10-12-05 3300 XL 8 mm Probe |
| Manufacturer | Bently Nevada |
| Product Type | 3300 XL 8 mm Probe |
| Part Number | 330103-00-07-10-12-05 |
| Dimensions | 112.3x1.6x1.6cm |
| Weight | 0.08kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Condition | New & Original in Factory Packing |
| Unthreaded Length Option | 00 mm |
| Overall Case Length Option | 70 mm |
| Total Length Option | 1.0 meter (3.3 feet) |
| Connector and Cable-Type Option | Miniature coaxial ClickLoc connector, FluidLoc cable |
| Agency Approval Option | CSA, ATEX, IECEx Approvals |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 303 or 304 stainless steel (SST) |
| Operating and Storage Temperature | -52°C to +177°C (-62°F to + 350°F) |
| Armor (optional on both) | Flexible AISI 302 or 304 SST with FEP outer jacket |
Compatible with 3500 Monitoring System and 3300 XL Series Proximitors
Uses FluidLoc cable technology for enhanced signal stability and protection
Miniature coaxial ClickLoc connector for secure installation
Optional dual redundant configuration for high system reliability
Universal M10 x 1 thread mounting capability
Occupies only one probe position per measurement point
CSA, ATEX, and IECEx certified for industrial safety compliance
Compact and lightweight design (0.08 kg)
Optional stainless steel armor with FEP outer jacket for harsh environments
High-grade materials: PPS probe tip and AISI 303/304 stainless steel housing
High-precision eddy current sensing ensures accurate vibration and displacement data
Stable signal transmission via FluidLoc cable minimizes noise and interference
Operating temperature range: -52°C to +177°C, suitable for extreme environments
Dual probe configuration improves system uptime and fault tolerance
Automatic failure detection and switchover enhances monitoring reliability
Optimized for continuous industrial operation in critical machinery systems
Long-term durability with corrosion-resistant materials and reinforced cable options
Q1: What is the main application of the Bently Nevada 330103-00-07-10-12-05?
A1: The 330103-00-07-10-12-05 is used for vibration and position monitoring in rotating machinery within industrial monitoring systems.
Q2: Does the 330103-00-07-10-12-05 support redundancy?
A2: Yes, the 330103-00-07-10-12-05 supports dual redundant configurations with automatic switchover to a backup probe if the primary fails.
Q3: What system is the 330103-00-07-10-12-05 compatible with?
A3: It is designed for use with the Bently Nevada 3500 monitoring system and 3300 XL probe infrastructure.
Q4: What communication technology does it use?
A4: The 330103-00-07-10-12-05 uses eddy current sensing combined with FluidLoc cable technology for stable signal transmission.
Q5: Can the 330103-00-07-10-12-05 be used in harsh environments?
A5: Yes, it operates between -52°C and +177°C and uses stainless steel construction and optional armored cable for durability.
