Product Name: Analog Control Station
Brand Name: ABB
Model Number: IISAC01
Place of Origin: Sweden
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Commercial Terms
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | ABB IISAC01 Analog Control Station |
| Manufacturer | ABB |
| Product Type | Analog Control Station |
| Part Number | IISAC01 |
| Estimated shipping dimensions | 7.2x25x14.5cm |
| Weight | 0.76kg |
| Place of shipment | Xiamen, China |
| Country of origin | SWEDEN |
| Serial Communication | RS-485 |
| Communication Rate (Baud) | 5 kbaud or 40 kbaud |
| Power Consumption | Approx. 540 mA @ 24 VDC |
| Current Range | 3 ~ 21 mA |
| Maximum Load | 600 Ω |
| Maximum Inductance | 600 mH |
| Accuracy | ±2.0% of span @ 25°C (77°F) |
| D/A Resolution | 8 bit |
The ABB IISAC01 is an Analog Control Station designed for single-loop process control and monitoring applications in industrial automation systems. It communicates serially with master control modules within ABB Harmony and distributed control system (DCS) environments, enabling reliable visualization and adjustment of process variables, setpoints, and actuator operations.
The ABB IISAC01 provides stable analog control performance with integrated communication capability, making it suitable for complex industrial process management. Its high-resolution display and precise signal handling support efficient operator interaction and accurate process supervision in demanding applications.
Designed for continuous industrial operation, the ABB IISAC01 supports RS-485 serial communication with selectable baud rates of 5 kbaud or 40 kbaud. With compact dimensions, low power consumption, and dependable analog output characteristics, the module is well suited for integration into ABB automation and control architectures.
Q1: What is IISAC01 used for?
A1: IISAC01 is used for single-loop process control and monitoring in industrial automation and ABB DCS systems.
Q2: What communication interface does IISAC01 support?
A2: IISAC01 supports RS-485 serial communication for integration with ABB control systems.
Q3: What baud rates are available for IISAC01?
A3: IISAC01 supports selectable communication rates of 5 kbaud and 40 kbaud.
Q4: What is the analog output range of IISAC01?
A4: IISAC01 provides an analog current range from 3 mA to 21 mA.
Q5: What is the accuracy of IISAC01?
A5: IISAC01 offers an accuracy of ±2.0% of span at 25°C (77°F).
Q6: Can IISAC01 be integrated into ABB Harmony systems?
A6: Yes, IISAC01 is designed for integration with ABB Harmony and other ABB DCS automation systems.
|
