Product Name: Analog Input Slave Module
Brand Name: ABB
Model Number: IMASM01
Place of Origin: Sweden
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | ABB IMASM01 Analog Input Slave Module |
| Manufacturer | ABB |
| Product Type | Analog Input Slave Module |
| Part Number | IMASM01 |
| Estimated shipping dimensions | 3.5x31x17.5cm |
| Weight | 0.24 kg |
| Place of shipment | Xiamen, China |
| Country of origin | Sweden |
| Accuracy | 0.10% |
| Resolution | Up to 16 bits |
| Response Time | ≤1ms |
| Working Voltage | 24V DC |
| Communication Protocols | Modbus RTU, Ethernet/IP |
| Slot Occupancy | One standard slot in Infi 90 rack |
The ABB IMASM01 is a high-precision analog signal acquisition module designed for the ABB Infi 90 Distributed Control System (DCS). It functions as a key interface between field analog devices and the system backplane, converting process signals into reliable digital data for monitoring and control.
The module supports multiple standard industrial signal types, including 4–20 mA DC, ±10 VDC, and 0–10 VDC inputs. Each channel is individually configurable, allowing flexible integration of different sensor types within a single module. With up to 16-bit resolution and 0.1% accuracy, it ensures stable and precise data conversion for critical process applications.
Built with galvanic isolation between field inputs and the backplane, the IMASM01 reduces signal interference, eliminates ground loop issues, and improves overall system stability. It is designed for rack-based installation and integrates seamlessly into existing Infi 90 and Net 90 architectures.
High-Precision Signal Conversion
The ABB IMASM01 delivers up to 16-bit resolution with 0.1% accuracy, ensuring highly reliable and stable analog-to-digital signal conversion for industrial process monitoring.
Flexible Multi-Signal Compatibility
It supports a wide range of industrial input types, including 4–20 mA and multiple voltage ranges, allowing seamless integration with diverse field instruments.
Channel-Level Configuration Flexibility
Each input channel can be independently configured, enabling mixed-signal and multi-sensor applications within a single module.
Strong Electrical Isolation Performance
Built-in galvanic isolation between field inputs and the backplane reduces noise, prevents ground loop issues, and improves overall system stability.
Improved System Reliability
Advanced signal conditioning and monitoring functions help detect abnormal conditions early, enhancing process safety and operational continuity.
Seamless Legacy System Integration
Designed for ABB Infi 90 and Net 90 architectures, the module ensures smooth integration into existing DCS environments without major system redesign.
The ABB IMASM01 delivers stable and accurate analog signal processing performance through high-resolution conversion technology. It ensures consistent acquisition of process variables such as temperature, pressure, flow, and level, maintaining signal integrity even in electrically noisy industrial environments.
The module improves system efficiency through channel-level configurability, allowing different sensor types and signal ranges to be combined within a single hardware unit. Its galvanic isolation significantly reduces interference and prevents ground loop issues, resulting in more stable long-term operation and reduced maintenance requirements.
Designed for continuous industrial use, the IMASM01 supports reliable operation in control cabinet environments with IP20 protection. Its integration within the Infi 90 architecture ensures efficient data transmission to the DCS backplane, enabling real-time monitoring and optimized process control across large-scale industrial systems.
1. What industries commonly use the ABB IMASM01?
The ABB IMASM01 is widely used in power plants, oil and gas, chemical processing, and water treatment industries.
2. What systems is the ABB IMASM01 compatible with?
The ABB IMASM01 is designed for ABB Infi 90 and Net 90 Distributed Control Systems.
3. How accurate is the ABB IMASM01?
The ABB IMASM01 provides up to 16-bit resolution with 0.1% measurement accuracy.
4. Does the ABB IMASM01 provide electrical isolation?
Yes. The ABB IMASM01 includes galvanic isolation between field inputs and the DCS backplane.
5. Can each channel of the ABB IMASM01 be configured separately?
Yes. The ABB IMASM01 allows individual configuration of each input channel.
6. What problem does the ABB IMASM01 solve in industrial systems?
The ABB IMASM01 improves signal integrity by reducing interference, eliminating ground loops, and ensuring accurate analog-to-digital conversion.
