Product Name:High Level Analog Input
Brand Name:Honeywell
Model Number:MC-PAIH03 51304754-150
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Honeywell |
Model Number: |
MC-PAIH03 51304754-150 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Description |
|
Model |
MC-PAIH03 51304754-150 |
|
Input Type |
Voltage / Current (2-wire & self-powered transmitters) |
|
Channels |
16 differential inputs |
|
A/D Resolution |
16-bit (14-bit effective) |
|
Input Range |
0–5 V / 4–20 mA |
|
Scan Rate |
4 samples/sec per channel |
|
Accuracy |
±0.075% FS @ 23°C |
|
CMRR |
70 dB |
|
Dimensions |
3x31.3x27.8cm |
|
Weight |
0.58kg |
|
Operating Temp |
0°C to 50°C |
|
Storage Temp |
-40°C to 85°C |
MC-PAIH03 51304754-150is a high level analog input processor designed for Honeywell TPS control systems, supporting accurate acquisition of voltage and current signals from industrial field devices. It is engineered for reliable data processing in demanding automation environments where stability and precision are essential.
The module is compatible with multiple FTA models includingMU-TAIH02,MU-TAIH12, andMU-TAIH52, enabling flexible system integration. It supports up to 16 differential input channels with high-resolution A/D conversion for precise signal interpretation and stable control performance.
With strong noise immunity, fast scanning capability, and built-in signal conditioning functions,MC-PAIH03 51304754-150ensures dependable operation in process industries such as power generation, chemical processing, and heavy manufacturing. Its modular design enhances system scalability and maintenance efficiency.
Q1: What is MC-PAIH03 used for?
A1: It is used for high-precision analog signal acquisition in Honeywell TPS industrial control systems.
Q2: How many input channels does MC-PAIH03 support?
A2: It supports 16 differential analog input channels.
Q3: Which FTAs are compatible with MC-PAIH03?
A3: It works with MU-TAIH02, MU-TAIH12, MU-TAIH52 and related TAIH series FTAs.
Q4: What industries commonly use this module?
A4: It is widely used in power plants, chemical plants, steel mills, and manufacturing automation.
Q5: Does MC-PAIH03 support current and voltage inputs?
A5: Yes, it supports both voltage signals and 4–20 mA current inputs.
| number | describe |
|---|---|
| MC-PAIH03 | High Level Analog Input Processor (16 Inputs) |
| MC-PSTX03 | Smart Transmitter Interface (Multivariable) Processor (16 Inputs) |
| MC-PSDX02 | Serial Device Interface Processor (16 Points/Port) |
| MC-PSIM11 | Serial Interface Processor (16 Points/Port) |
| MC-PAIL02 | Low Level Analog Input Processor (8 Inputs) |
| MC-PLAM02 | Low Level Analog Input Multiplexer Processor (32 Inputs) |
| MC-PRHM01 | Remote Hardened Multiplexer IOP (32-Points) |
| MC-PPIX02 | Pulse Input Processor (8 Inputs) |
| MC-PAOX03 | Analog Output Processor (8 Outputs) |
| MC-PAOY22 | Analog Output 16 Processor (16 Outputs) |
| MC-PDIX02 | Digital Input Processor (32 Inputs) |
| MC-PDIS12 | Digital Input Processor for Sequence of Events (32 Inputs) |
| MC-PDIY22 | Digital Input 24 Vdc Processor (32 Inputs) |
| MC-PDOX02 | Digital Output Processor (16 Outputs) |
| MC-PDOY22 | Digital Output 32 Processor (32 Outputs) |
