ABB IMDSO14 Digital Output Slave

Product Name: Digital Output Slave

Brand Name: ABB

Model Number: IMDSO14

Place of Origin: SWEDEN

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

Overview
Commercial Terms
Description
Functions
Specifications
Advantage
Performance & Efficiency
Installation & Integration
Recommended Products

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Description

The ABB IMDSO14 Digital Output Slave is a high-density industrial output module designed for use in ABB automation and process control systems. Manufactured by ABB in Sweden, it provides reliable 16-channel open-collector digital output capability for controlling field devices such as relays, solenoids, indicators, and actuators. Its compact rack-mounted design makes it suitable for space-efficient integration into distributed control systems and industrial automation architectures.

The module operates using a +5 V DC backplane power supply with low internal power consumption, while delivering 24 V DC rated output switching through solid-state open collector technology. This ensures stable, fast, and maintenance-free switching performance in continuous industrial operation environments.

Functions

Provides 16-channel digital output control for industrial automation systems.
Switches external field devices such as relays, valves, and actuators.
Uses open collector output architecture for flexible load control.
Receives control signals from ABB system backplane architecture.
Supports real-time execution of automation and process control commands.
Interfaces with distributed control system (DCS) output modules.
Enables coordinated control of multiple industrial devices simultaneously.
Supports high-speed switching for time-critical control applications.

Specifications

Product Name	ABB IMDSO14 Digital Output Slave
Manufacturer	ABB
Product Type	Digital Output Slave
Part Number	IMDSO14
Weight	0.2kg
Estimated shipping dimensions	3.7x31.7x17.8cm
Place of shipment	Xiamen, China
Country of origin	SWEDEN
Signal Type	Digital Output
Number of Channels	16-channel open collector digital outputs
Output Type	Open collector (solid-state switching)
Power Requirement	+5 VDC from backplane
Power Consumption	~370 mA
Rated Voltage	24 V DC
Application	Industrial automation and process control systems
