ABB IPMON01 Power Montior Module

Product Name: Power Montior Module

Brand Name: ABB

Model Number: IPMON01

Place of Origin: Sweden

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

Overview
Connect With Us
Specifications
Alternative Name
Description
Functions
Advantage
Product Recommendations
Recommended Products

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Winnie
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Connect With Us

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Specifications

Product Name	ABB IPMON01 Power Montior Module
Manufacturer	ABB
Product Type	Power Montior Module
Part Number	IPMON01
Weight	0.98kg
Estimated shipping dimensions	3.4x41.5x21.8cm
Place of shipment	Xiamen, China
Country of origin	Sweden
AC Input Sensing	120/240 VAC ±10 %
DC Input Sensing	125 VDC ±20 %
Isolation	2300 VAC rms
Aux Output	24 VDC ±5 %
Operating Temperature	–20 °C to +70 °C
Storage Temperature	–40 °C to +85 °C
Humidity	5 % – 95 % RH non-condensing

Alternative Name

IPMON01 Power Monitoring Module

ABB System Power Monitor IPMON01

IPMON01 Power Supply Monitoring Unit

ABB IPMON01 Voltage Monitoring Module

IPMON01 AC/DC Power Supervision Module

ABB Industrial Power Monitor Module

IPMON01 Power Status Monitoring Board

ABB Automation Power Monitor IPMON01

IPMON01 System Power Diagnostic Module

Description

The ABB IPMON01 Power Monitor Module is an industrial monitoring module designed to supervise and monitor power conditions within ABB automation and control systems. It provides reliable sensing of both AC and DC power inputs, helping maintain stable system operation and ensuring that connected equipment receives proper voltage levels.

The module supports AC input sensing for 120/240 VAC systems and DC input sensing for 125 VDC systems, making it suitable for a wide range of industrial power configurations. It also features a 24 VDC auxiliary output for supporting additional system functions and monitoring applications.

Designed for harsh industrial environments, the IPMON01 offers high electrical isolation, wide operating and storage temperature ranges, and resistance to humidity. Its robust design enhances system reliability and supports long-term operation in critical automation applications.

Functions

Monitors AC input voltage levels (120/240 VAC)
Monitors DC input voltage levels (125 VDC)
Detects and supervises power system conditions
Provides 24 VDC auxiliary output for supporting devices
Protects control systems through high electrical isolation
Supports stable operation of ABB automation systems
Assists in power diagnostics and system maintenance

Advantage

Supports both AC and DC power monitoring
High isolation rating (2300 VAC rms) for improved safety
Wide operating temperature range (-20°C to +70°C)
Reliable operation in harsh industrial environments
Auxiliary 24 VDC output for additional flexibility
Enhances system stability and power reliability
Compact design for easy control cabinet integration
Suitable for continuous industrial automation applications
