Product Name:Termination Module Digital Inputs
Brand Name:ABB
Model Number:NIDI01
Country of Origin:Sweden
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
ABB |
Model Number: |
NIDI01 |
Country of Origin: |
Sweden |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Specification | Details |
|---|---|
| Product Model | NIDI01 |
| Manufacturer | ABB Bailey |
| Product Type | Digital Input Termination Module |
| Compatible Module | IMDSI02 Digital Slave Input Module |
| Supported Input Signals | 24 VDC, 125 VDC, 120 VAC |
| Configuration Method | Jumper Selectable |
| Terminal Capacity | 16 Digital Input Channels |
| Communication Interface | Field Wiring Termination |
| Compatible Cables | NKTM01, NKTU01, NKTU02 |
| System Platform | ABB INFI 90 |
| Mounting Method | Cabinet/Termination Assembly Mounting |
| Dimensions (Approx.) | 190 × 120 × 35 mm |
| Weight (Approx.) | 0.3 kg |
NIDI01 is a digital input termination module engineered for ABB Bailey INFI 90 process control systems. It provides a reliable interface between field devices and digital input modules, ensuring accurate signal transmission and stable communication within industrial automation environments. The module supports multiple input signal types, including 24 VDC, 125 VDC, and 120 VAC applications.
Designed to operate alongside IMDSI02, IMMFP01, IMMFP02, and IMLMM02 modules, the NIDI01 simplifies field wiring and signal termination while improving installation efficiency. Flexible jumper configurations allow users to adapt the module to different digital input requirements.
The NIDI01 is widely used in power generation, process industries, manufacturing facilities, and infrastructure projects where dependable digital signal acquisition and system reliability are essential for continuous plant operation.
Power Plants: Used for generator status monitoring, digital alarm collection, relay signal interfacing, and plant equipment supervision.
Substations: Supports breaker status monitoring, protection relay inputs, switchgear indication signals, and control system integration.
Chemical Plants: Integrates field contact signals, process alarms, and safety monitoring devices into distributed control systems.
Steel Mills: Collects digital equipment status signals and supports automation systems operating in harsh industrial environments.
Machinery Manufacturing Plants: Provides digital input termination for automated production lines, robotic workstations, packaging systems, and machine control applications.
Q1: What is the primary function of the NIDI01?
A1: The NIDI01 serves as a digital input termination module for connecting field signals to ABB INFI 90 control systems.
Q2: Which input voltages are supported by the NIDI01?
A2: The module supports 24 VDC, 125 VDC, and 120 VAC digital input signals.
Q3: Which module commonly works with the NIDI01?
A3: The NIDI01 is primarily used with the IMDSI02 Digital Slave Input Module.
Q4: How is the NIDI01 configured for different signal types?
A4: Configuration is performed through onboard jumper settings that match the required input application.
Q5: In which industries is the NIDI01 widely used?
A5: It is commonly deployed in power generation, substations, chemical processing, manufacturing, and industrial automation facilities.
|
