ABB RPBA-01 Profibus Adapter

Product Name: Profibus Adapter

Brand Name: ABB

Model Number: RPBA-01

Place of Origin: Sweden

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

Overview
Contact Info
Parameter Information
Description
Functions
Features
FAQ
Recommendations
Recommended Products

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Parameter Information

Product Name	ABB RPBA-01 Profibus Adapter
Manufacturer	ABB
Product Type	Profibus Adapter
Part Number	RPBA-01
Estimated shipping dimensions	6.6x3.5x9.4cm
Weight	0.06kg
Place of shipment	Xiamen, China
Country of origin	SWEDEN
Mounting	Into the option slot on the control board of the drive.
Degree of protection	IP20
Maximum cyclic I/O data size	28 bytes in, max 28 bytes out, max. 56 bytes total
Maximum acyclic I/O data size	240 bytes in, max. 240 bytes out, max. 480 bytes total
Maximum User Parameter data/Diagnostics length	26 bytes
Connectors	34-pin parallel bus connector; 9-pin female DSUB connector
Current consumption	350 mA max. (5 V), supplied by the control board of the drive
Estimated min. lifetime	100 000 h
Approval	All materials UL/CSA-approved

Description

The ABB RPBA-01 is a PROFIBUS DP Adapter Module designed for ABB drive systems to enable reliable fieldbus communication and remote drive control. Acting as a communication interface between ABB frequency converters and PROFIBUS networks, the module allows bidirectional data exchange for process automation applications, including control commands, monitoring signals, and diagnostic information.

The ABB RPBA-01 supports both cyclic and acyclic communication with high data transfer capacity, making it suitable for real-time industrial automation environments. The module enables efficient transmission of control data, parameter settings, status information, and fault diagnostics, helping improve operational efficiency and simplify system integration within industrial control networks.

Designed for seamless installation, the ABB RPBA-01 mounts directly into the option slot of the drive control board without requiring external power supply connections. Its compact IP20-rated design, UL/CSA-approved materials, and long estimated service life of 100,000 hours ensure dependable long-term operation in demanding industrial environments.

Functions

Enables PROFIBUS DP communication for ABB drives
Supports remote drive control and monitoring
Transfers cyclic and acyclic process data
Exchanges operating status and fault diagnostics information
Supports parameter configuration through fieldbus communication
Integrates ABB drives into industrial automation networks
Simplifies centralized drive management and maintenance

Features

PROFIBUS DP slave communication interface
Maximum cyclic I/O data size: 28 bytes input and 28 bytes output
Maximum acyclic I/O data size: 240 bytes input and 240 bytes output
Supports up to 26 bytes of parameter and diagnostic data
34-pin parallel bus connector and 9-pin female DSUB connector
Direct mounting into ABB drive control board option slot
Powered directly by the drive control board
Maximum current consumption: 350 mA at 5 V
Compact IP20-rated industrial design
UL/CSA-approved materials for industrial compliance
Estimated minimum lifetime of 100,000 operating hours
Plug-and-play installation for simplified integration

FAQ

Q1: Can RPBA-01 support remote monitoring of ABB drives?

A1: Yes, RPBA-01 enables remote monitoring of drive status, operating data, and fault information through the PROFIBUS DP network.

Q2: What type of connector is used on RPBA-01?

A2: RPBA-01 includes a 34-pin parallel bus connector and a 9-pin female DSUB connector for communication connections.

Q3: What is the maximum acyclic data capacity of RPBA-01?

A3: RPBA-01 supports up to 240 bytes input and 240 bytes output for acyclic communication data.

Q4: Is RPBA-01 suitable for long-term industrial operation?

A4: Yes, RPBA-01 is designed for industrial environments with an estimated minimum service life of 100,000 hours.

Q5: What is the current consumption of RPBA-01?

A5: RPBA-01 has a maximum current consumption of 350 mA at 5 V supplied by the drive control board.

Q6: Does RPBA-01 comply with industrial certification standards?

A6: Yes, RPBA-01 uses UL/CSA-approved materials to meet industrial safety and reliability standards.
