Product Name: Digital Input Module
Brand Name: ABB
Model Number: SPDSI22
Place of Origin: SWEDEN
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | ABB SPDSI22 Digital Input Module |
| Manufacturer | ABB |
| Product Type | Digital Input Module |
| Part Number | SPDSI22 |
| Weight | 0.24 kg |
| Estimated shipping dimensions | 3.7x31.3x17.7cm |
| Place of shipment | Xiamen, China |
| Country of origin | SWEDEN |
| Number of Channels | 16 Channels (16 CH) |
| Input Type | Universal Digital Inputs |
| Configuration | 32 Jumpers |
| Supported Input Voltages | 24 VDC; 48 VDC; 125 VDC; 120 VAC |
| Voltage | 24 VDC |
| Consumption | ≤ 10 W |
| Operating Temperature | -40°C to +70°C (-40°F to +158°F) |
The ABB SPDSI22 Digital Input Module is a versatile industrial input module designed to provide reliable digital signal acquisition for ABB automation and control systems. Featuring 16 universal digital input channels, the module is capable of monitoring a wide range of field devices, including switches, relays, pushbuttons, limit switches, and status contacts. Its flexible input design supports multiple voltage levels, making it suitable for diverse industrial applications and simplifying system integration.
Manufactured by ABB in Sweden, the SPDSI22 is engineered for demanding industrial environments where dependable signal monitoring is essential for safe and efficient operation. With support for 24 VDC, 48 VDC, 125 VDC, and 120 VAC input signals, as well as an extended operating temperature range of -40°C to +70°C, the module offers exceptional flexibility and durability for process control, power generation, and industrial automation systems.
The SPDSI22 functions as a digital signal interface between field devices and the control system. It continuously monitors the status of connected devices and converts incoming digital signals into data that can be processed by the controller. This enables real-time detection of equipment states, alarm conditions, process events, and operational commands throughout the automation system.
The module's 16 input channels allow multiple field signals to be monitored simultaneously, providing operators and control systems with accurate status information. Through its configurable jumper settings, the SPDSI22 can be adapted to different voltage requirements, making it a flexible solution for applications that involve mixed signal types and varying field device configurations.
The ABB SPDSI22 is designed for integration with ABB industrial control and automation platforms and is compatible with:
Its universal input capability, wide voltage compatibility, and rugged industrial design make the SPDSI22 an ideal digital input solution for a broad range of process control, power, and manufacturing automation applications.
