Product Name:3300 XL 11 mm Proximity Probes
Brand Name:BENTLY NEVADA
Model Number:330703-050-120-10-02-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330703-050-120-10-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Specification |
|
Model |
330703-050-120-10-02-00 |
|
Series |
Bently Nevada 3300 XL 11 mm |
|
Probe Type |
Non-contact proximity probe |
|
Thread Type |
M14 x 1.5 (metric) |
|
Total Length |
5.0 m system configuration |
|
Output Sensitivity |
3.94 V/mm (100 mV/mil) |
|
Linear Range |
Approx. 0.5 – 4.5 mm |
|
Operating Temp |
-52°C to +177°C |
|
Storage Temp |
-52°C to +177°C |
|
Frequency Response |
0 – 8 kHz |
|
Connector Type |
ClickLoc gold-plated connector |
|
Cable Type |
75Ω triaxial FEP insulated |
|
Dimension (Probe Head) |
2.5x2x122cm |
|
Weight (Probe only) |
0.14kg |
|
Weight (System) |
~0.7 kg (typical full system) |
The Bently Nevada 330703-050-120-10-02-00 3300 XL 11 mm proximity probe is engineered for high-precision monitoring of vibration and axial displacement in rotating machinery. As part of the 3300 XL 11 mm Transducer System, it delivers stable non-contact measurement performance for critical industrial assets operating under demanding conditions.
Integrated within the Bently Nevada 3300 XL series, including probe, extension cable, and Proximitor sensor, the system provides reliable signal output with extended linear range capability. Its 11 mm sensing tip enhances measurement accuracy for thrust position, shaft movement, and speed reference applications.
Designed for industrial-grade durability, 330703-050-120-10-02-00 supports harsh environments such as turbines, compressors, and reciprocating machines. It ensures interchangeability with compatible XL components, reducing maintenance downtime and simplifying system upgrades.
Q1: What is the 330703-050-120-10-02-00 used for?
A1: It is used for measuring vibration, shaft position, and axial displacement in rotating machinery.
Q2: Is it compatible with other 3300 XL components?
A2: Yes, it is fully compatible and interchangeable within the Bently Nevada 3300 XL system.
Q3: What is the operating temperature range?
A3: It operates reliably from -52°C to +177°C in industrial environments.
Q4: Where is this probe commonly applied?
A4: It is widely used in power plants, steel mills, chemical plants, and manufacturing systems.
Q5: Does it require calibration during replacement?
A5: No, it is factory-calibrated and supports plug-and-play installation without field calibration.
| Number | Description |
|---|---|
| 40971-04 | 50 Ω cable with two BNC (M) connectors. Used with adapter 01609137 and 01609138 for checking transducer system performance from Proximitor Sensor test pin holes. |
| 04310310 | 3300 XL Proximitor Sensor panel-mount screws. Includes four 6-32 UNC thread forming mounting screws for standard 3300 XL housings. |
| 03200006 | Silicone self-fusing tape (9.1 m / 10 yd roll). Provides electrical isolation and environmental protection for connectors. Not recommended inside machine casing. |
| 40113-02 | Connector Protector Kit for 3300 XL probes and extension cables, including connector protectors and installation tools. |
| 136536-01 | Connector protector adapter enabling compatibility between legacy 3300 connector kits and 3300 XL probe/cable connectors. |
| 40180-02 | Connector protectors package containing 10 pairs of protective connector sets for 3300 XL probes and extension cables. |
| 03839410 | Male connector protector installed on extension cable to protect probe-to-cable connection from environmental contamination. |
| 03839420 | Female connector protector installed on probe lead or extension cable to ensure environmental sealing of connector joints. |
| 330153-01 | 3300 XL connector kit including male/female ClickLoc connectors, sleeves, and silicone tape for probe and extension cable assembly. |
| 163356 | Connector crimp tool kit including ClickLoc inserts and installation instructions, supplied with protective carrying case. |
