Product Name:3300 XL Standard Extension Cable
Brand Name:BENTLY NEVADA
Model Number:330130-080-00-05
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330130-080-00-05 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Description |
|---|---|
| Model | 330130-080-00-05 |
| Cable Length | 8.0 meters |
| Cable Type | 75Ω triaxial, FEP insulated |
| Capacitance | 69.9 pF/m (typical) |
| Operating Temperature | -52°C to +177°C |
| Connector Type | Gold-plated ClickLoc connectors |
| Minimum Bend Radius | 25.4 mm |
| Dimension | 21x21x2cm |
| Weight | 0.28kg |
The330130-080-00-05extension cable is a key component within the Bently Nevada 3300 XL proximity transducer system, engineered to deliver stable signal transmission between probes and Proximitor sensors. Designed for industrial monitoring environments, this model ensures accurate vibration and position data transfer while maintaining system integrity over extended distances.
As part of the 3300 XL series, including models such as330130-030-00-05and330130-070-00-05, the330130-080-00-05features an 8.0-meter standard cable length and supports reliable operation in demanding conditions. Its precision-matched impedance and robust insulation structure minimize signal loss and external interference.
Optimized for compliance with global certifications, this cable integrates seamlessly into API 670-compliant systems, making it suitable for high-performance machinery protection and condition monitoring applications.
Q1:What is the primary function of the 330130-080-00-05 cable?
A1:It transmits signals between the proximity probe and Proximitor sensor in monitoring systems.
Q2:Is the 330130-080-00-05 compatible with other 3300 XL components?
A2:Yes, it is fully compatible and interchangeable within the 3300 XL system.
Q3:What environments is this cable suitable for?
A3:It is designed for industrial environments with high temperature, vibration, and EMI conditions.
Q4:Does the cable require special tools for installation?
A4:No, it uses ClickLoc connectors that allow easy, tool-free installation.
Q5:Can this model be used in hazardous areas?
A5:Yes, with appropriate system configuration, it meets international certification requirements.
| Number | Description |
|---|---|
| 141078 | 3300 XL 8 mm and 3300 5 mm Proximity Transducer System manual |
| 175751 | 3300 XL stainless steel housing (12”×12”×6”), supports up to 8 DIN-mounted or 6 panel-mounted Proximitor sensors, ATEX Zone 0/1 certified |
| 176467 | 3300 XL stainless steel housing (12”×8”×6”), supports up to 4 Proximitor sensors (DIN or panel mount), ATEX Zone 0/1 certified |
| 330181 | 3300 XL stainless steel housing (13”×9.5”×7”), supports up to 8 DIN-mounted or 6 panel-mounted sensors, suitable for hazardous areas, ATEX & North American certifications |
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor, twisted, shielded cable with drain wire (length customizable) |
| 138492-01 | Replacement panel-mount mounting pad |
| 138493-01 | Replacement DIN-mount mounting pad |
| 148722-01 | 3300 XL test plug with 3-pin adapter and color-coded leads for sensor testing without disconnecting wiring |
| 04310310 | Proximitor sensor panel-mount screw (6-32 UNC), 4 required per sensor |
| 03200006 | Silicone self-fusing tape (9.1 m roll) for connector insulation and environmental protection |
| 40113-02 | Connector protector kit for 3300 XL probes and extension cables (includes installation tools) |
| 136536-01 | Connector protector adapter for compatibility with pre-1998 installation tools |
| 40180-02 | Connector protector set, includes 10 pairs for probes and extension cables |
| 03839410 | 75Ω triaxial male connector protector for extension cable environmental protection |
| 03839420 | 75Ω triaxial female connector protector for probe and sensor connection protection |
| 04301007 | 3/8-24 probe lock nut with safety wire holes for secure installation |
| 04301008 | M10 × 1 probe lock nut with safety wire holes for secure installation |
