Product Name: 3300 NSv Proximity Probe
Brand Name: Bently Nevada
Model Number: 330910-10-22-10-01-CN
Place of Origin: United States
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
overview
| Product Name | 3300 NSv Proximity Probe |
| Brand Name | Bently Nevada |
| Model Number | 330910-10-22-10-01-CN |
| Place of Origin | USA |
| Warranty | 12 months |
| Payment Methods | T/T |
| Shipment | DHL/UPS/EMS/Fedex... |
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
| Product Name | BENTLY NEVADA 330910-10-22-10-01-CN 3300 NSv Proximity Probe |
| Manufacturer | BENTLY NEVADA |
| Product Type | 3300 NSv Proximity Probe |
| Part Number | 330910-10-22-10-01-CN |
| Dimensions | 110x2x2cm |
| Weight | 0.16kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Condition | New & Original in Factory Packing |
| Unthreaded Length Option | 10=100 mm |
| Overall Case Length Option | 22=220 mm |
| Total Length Option | 10=1.0 meter (39 in) |
| Connector and Cable-Type Option | 01=Miniature coaxial ClickLoc connector with connector protector, standard cable |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 304 stainless steel (SST) |
| Cable Type | 75 Ω coaxial, FEP-insulated |
| Load Resistance | 10 kΩ |
| Standard Probe Gap | 1.0 mm (40 mils) |
| Operating Temperature | -52°C to +177°C (-62°F to +351°F) |
The Bently Nevada 330910-10-22-10-01-CN 3300 NSv Proximity Probe is a compact eddy-current proximity probe specifically designed for non-contact measurement of shaft vibration and position in applications with limited installation space. It is ideal for situations where counter bore, sideview, or rearview constraints prevent the use of standard 3300 or 3300 XL 5 mm and 8 mm probes.
Optimized for small targets, it accurately measures radial vibration on shafts smaller than 51 mm and axial position on surfaces smaller than 15 mm. As part of the 3300 XL NSv Transducer System, it converts gap changes between the probe tip and conductive surfaces into proportional voltage signals, enabling precise monitoring of both static and dynamic machine conditions. Its robust construction and wide temperature tolerance ensure reliable operation in demanding industrial environments.
The Bently Nevada 330910-10-22-10-01-CN 3300 NSv Proximity Probe features a 100 mm unthreaded length and a 220 mm overall case length, with a total cable length of 1.0 meter (39 inches). It uses a miniature coaxial ClickLoc connector with connector protector and a 75 Ω FEP-insulated coaxial cable for stable signal transmission.
The probe tip is made of polyphenylene sulfide (PPS), while the housing is constructed from AISI 304 stainless steel for durability. It operates with a 10 kΩ load resistance and maintains a standard probe gap of 1.0 mm (40 mils). The operating and storage temperature range is -52°C to +177°C (-62°F to +351°F). The unit dimensions are 110 × 2 × 2 cm with a weight of 0.16 kg.
The Bently Nevada 330910-10-22-10-01-CN 3300 NSv Proximity Probe is specifically engineered for tight and constrained installation environments, enabling accurate measurements where standard probes cannot be used. Its compact design supports high-precision monitoring of small shafts and targets.
The durable PPS tip and stainless steel housing provide excellent resistance to temperature, corrosion, and mechanical stress. The ClickLoc connector with protective design enhances connection reliability and simplifies installation. Wide temperature capability ensures stable performance in extreme industrial conditions. Additionally, it offers strong compatibility with existing 3300 XL NSv systems, enabling easy upgrades from legacy systems.
This Bently Nevada 330910-10-22-10-01-CN 3300 NSv Proximity Probe is widely used in monitoring systems for small or space-limited rotating machinery, including turbines, compressors, pumps, motors, and other industrial equipment. It is particularly suitable for applications involving small-diameter shafts or limited mounting access.
Typical industries include oil and gas, petrochemical processing, power generation, and manufacturing, especially where compact sensor solutions are required for precision monitoring.
The 330910-10-22-10-01-CN probe plays a critical role in machinery diagnostics by continuously monitoring shaft displacement and vibration. It enables early detection of faults such as imbalance, misalignment, and abnormal axial movement.
It also supports Keyphasor functions, tachometer signals, and zero-speed detection, providing essential data for speed and phase analysis. By delivering accurate real-time measurements, it supports predictive maintenance strategies, reduces the risk of unexpected failures, and enhances overall equipment protection, safety, and reliability.
