Product Name: Terminal Base
Brand Name: ABB
Model Number: TB511-ETH 1SAP111100R0270
Place of Origin: SWEDEN
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | ABB TB511-ETH 1SAP111100R0270 Terminal Base |
| Manufacturer | ABB |
| Product Type | Terminal Base |
| Part Number | TB511-ETH 1SAP111100R0270 |
| Weight | 0.16kg |
| Estimated shipping dimensions | 13.5x9.5x3cm |
| Place of shipment | Xiamen, China |
| Country of origin | SWEDEN |
| Communication Interface | D-SUB/RJ45/Terminals |
| Input Voltage Type | DC |
| Degree of Protection | IP20 |
| Supply Voltage | 24 V DC |
The ABB TB511-ETH 1SAP111100R0270 Terminal Base is an industrial interface and connection platform designed to support reliable signal, power, and communication distribution within ABB automation systems. It provides a structured termination point for field wiring and enables seamless integration of control modules into Ethernet-based industrial communication networks.
This terminal base is commonly used in distributed control and automation architectures where secure wiring, modular expansion, and standardized connectivity are required. Its compact and robust design ensures stable installation and efficient system organization inside control cabinets.
Signal Termination Interface
Provides secure termination points for field wiring, ensuring stable electrical connections.
Ethernet Communication Support
Enables data exchange via RJ45 interface for industrial Ethernet-based automation systems.
Wiring Organization Platform
Centralizes and organizes field connections to simplify system layout and maintenance.
Module Integration Support
Acts as a base interface for ABB control and automation modules.
Power Distribution Interface
Distributes 24 V DC supply to connected modules within the system architecture.
System Expansion Support
Facilitates modular expansion and replacement of automation components.
Compared to other industrial terminal bases, the ABB TB511-ETH 1SAP111100R0270 provides stronger Ethernet connectivity, improved wiring organization, and better modular integration capabilities. It is a practical and efficient solution for structured communication and power distribution in modern industrial automation systems.
The ABB TB511-ETH 1SAP111100R0270 Terminal Base delivers stable and efficient connectivity performance by providing a reliable interface for signal, power, and Ethernet communication in industrial automation systems. Its integration of RJ45-based Ethernet connectivity ensures fast and consistent data exchange between control modules and higher-level systems, supporting real-time automation performance.
With its 24 V DC operation and IP20-rated enclosure compatibility, the module maintains safe and stable performance within control cabinets. Its structured wiring design reduces installation complexity and improves maintenance efficiency, contributing to smoother system operation and enhanced overall reliability in ABB automation architectures.
