Product Name:Low Voltage Digital Input (24 volts DC)
Brand Name:Honeywell
Model Number:CC-PDIL51
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Honeywell |
Model Number: |
CC-PDIL51 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Description |
|
Product Model |
CC-PDIL51 |
|
Brand |
Honeywell |
|
Product Type |
Digital Input Module (24V DC) |
|
Compatible IOTA |
CC-TDIL51 / CC-TDIL61 |
|
Input Type |
Low-voltage DI signal |
|
Isolation |
3-way galvanic isolation |
|
Protection |
Reverse polarity & short-circuit protection |
|
Wiring |
Dry contact / NAMUR sensor support |
|
Installation |
DIN rail mounted FTA system |
|
Channels |
Single-channel modular design |
|
Operating Temp |
-40°C to +70°C |
|
Dimension |
5.5x16x14.5cm |
|
Weight |
0.3kg |
TheHoneywell CC-PDIL51is a reliable low-voltage digital input module designed for the Universal Marshalling Solution within Honeywell’s Experion® control architecture. It works with compatible I/O termination assemblies such asCC-TDIL51 / CC-TDIL61, enabling stable 24 VDC signal acquisition for industrial automation and process control systems. The module is engineered for high-density cabinet installations and supports flexible field wiring configurations through standardized marshalling design.
As part of Honeywell’s SCA ecosystem, theCC-PDIL51integrates seamlessly with other Series C and Universal I/O modules, ensuring consistent performance across distributed control environments. Its galvanic isolation and built-in protection features help maintain signal integrity even in electrically noisy or hazardous locations.
By separating field wiring from control electronics, theCC-PDIL51improves maintainability, reduces engineering complexity, and supports scalable system expansion in both greenfield and brownfield projects.
Q1: What is the CC-PDIL51 used for?
A1: It is used for acquiring 24V DC digital input signals in Honeywell control systems.
Q2: Which systems support CC-PDIL51?
A2: It is designed for Honeywell Experion® and Universal Marshalling SCA platforms.
Q3: Does CC-PDIL51 support isolation?
A3: Yes, it provides 3-way galvanic isolation for safe signal processing.
Q4: What field devices are compatible?
A4: It supports dry contacts and NAMUR-type sensors.
Q5: Is CC-PDIL51 suitable for hazardous environments?
A5: Yes, it is designed for industrial and HAZLOC-compatible installations when properly configured.
| IO Module | Description |
|---|---|
| CC-PDIL01 | CC-TDIL01, CC-TDIL11 — DI-24 Low Voltage Digital Input (24 VDC) |
| CC-PDIS01 | CC-TDIL01, CC-TDIL11 — DI-SOE Low Voltage Digital Input (24 VDC) |
| CC-PDOB01 | CC-TDOB01, CC-TDOB11 — DO-24B Bussed Low Voltage Digital Output (24 VDC) |
| CC-PDIL51 | CC-TDIL51, CC-TDIL61 — DI-24 Low Voltage Digital Input (24 VDC) |
| CC-PUIO31 | CC-TUIO31, CC-TUIO41 — UIO-2 Universal Input/Output Module |
