Product Name: NSV Probe
Brand Name: Bently Nevada
Model Number: 330901-11-25-10-01-00
Place of Origin: United States
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Tag
| Bently Nevada 3300 NSv Probe | Bearing Vibration Monitoring |
| 330901-11-25-10-01-00 | Compressor Monitoring Probe |
| Proximity Probe | Non-contact Displacement Sensor |
| Vibration Monitoring Sensor | 3300 NSv Series |
| Shaft Displacement Probe | Stainless Steel Probe |
| Eddy Current Sensor | PPS Tip Probe |
| Rotating Machinery Monitoring | ClickLoc Connector Probe |
| Condition Monitoring System | Industrial Automation Sensor |
| Compact Industrial Probe | Machinery Protection System |
| High-Speed Machinery Sensor | Predictive Maintenance Sensor |
The Bently Nevada 330901-11-25-10-01-00 is a 3300 NSv proximity probe designed for precise vibration and shaft displacement monitoring in compact and high-speed rotating machinery environments. It is commonly used in applications such as compressors, bearings, and industrial rotating equipment where installation space is limited but measurement accuracy is critical.
The probe features a PPS (polyphenylene sulfide) tip and an AISI 304 stainless steel housing, ensuring excellent durability, wear resistance, and corrosion protection. It is equipped with a 75 Ω FEP-insulated coaxial cable and a Miniature ClickLoc connector with connector protector for secure and reliable signal transmission.
With an operating temperature range of -52°C to +177°C, the 330901-11-25-10-01-00 delivers stable performance in extreme industrial environments. Its compact design, 1-meter cable length, and flexible installation configuration make it ideal for modern condition monitoring systems.
|
Sales |
|
|
|
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Winnie |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | Bently Nevada 330901-11-25-10-01-00 NSV Probe |
| Manufacturer | Bently Nevada |
| Product Type | NSV Probe |
| Part Number | 330901-11-25-10-01-00 |
| Dimensions | 112x1.1x1.1cm |
| Weight | 0.04kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Unthreaded Length Option | 1.1 in |
| Overall Case Length Option | 2.5 in |
| Total Length Option | 1.0 meter (39 in) |
| Connector and Cable-Type Option | Miniature coaxial ClickLoc connector with connector protector, standard cable |
| Agency Approval Option | Not required |
| Probe dc Resistance | 4.2 ± 0.5 Ω |
| Probe Tip Material | Polyphenylene sulfide (PPS). |
| Probe Case Material | AISI 304 stainless steel (SST). |
| Probe Cable Specifications | 75 Ω coaxial, fluoroethylene propylene (FEP) insulated |
| Operating Temperature | -52°C to +177°C (-62°F to +351°F) |
| Storage Temperature | -52°C to +177°C (-62°F to +351°F) |
1. What materials are used in 330901-11-25-10-01-00?
The 330901-11-25-10-01-00 uses a PPS probe tip and AISI 304 stainless steel housing for durability and corrosion resistance.
2. What is the cable length of 330901-11-25-10-01-00?
The 330901-11-25-10-01-00 comes with a standard cable length of 1.0 meter (39 inches).
3. What type of connector does 330901-11-25-10-01-00 use?
The 330901-11-25-10-01-00 uses a Miniature coaxial ClickLoc connector with a connector protector for secure installation.
4. Does 330901-11-25-10-01-00 require agency approvals?
No, the 330901-11-25-10-01-00 does not require additional CSA/ATEX/IECEx approvals.
5. What industries use 330901-11-25-10-01-00?
The 330901-11-25-10-01-00 is widely used in power generation, oil & gas, petrochemical, and industrial machinery monitoring applications.
6. Why is vibration monitoring important with 330901-11-25-10-01-00?
The 330901-11-25-10-01-00 helps detect early mechanical issues, reducing downtime, improving safety, and extending equipment lifespan.
7. Is 330901-11-25-10-01-00 suitable for compact installations?
Yes, the 330901-11-25-10-01-00 is specifically designed for compact environments with limited installation space.
