Product Name: Digital Input Module
Brand Name: YOKOGAWA
Model Number:ADV151-P53 S2
Country of Origin:JAPAN
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
YOKOGAWA |
Model Number: |
ADV151-P53 S2 |
Country of Origin: |
JAPAN |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
Delivery time in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
ADV151-P/ADV151-E (*1) |
|
Model |
ADV151-P/ADV151-E (*1) |
|
Number of input channels |
32 |
|
Rated input voltage (*2) |
24 V DC (sink/source) |
|
Input ON voltage |
18 to 26.4 V DC |
|
Input OFF voltage |
5.0 V DC or less |
|
Input current (at rated input voltage) |
4.1 mA±20 % / channel |
|
Maximum allowable input voltage |
30.0 V DC |
|
Withstanding voltage |
Between input signal and system: 2 kV AC, For 1 minute |
|
Functions |
|
|
Status input |
Function for detecting ON/OFF status |
|
Pushbutton input |
Function for counting the pushbutton edges |
|
SOE input |
Function for capturing the SOE data |
|
Input response time |
8 ms or less (for status input) |
|
Minimum ON detection time |
20 ms (for pushbutton input) |
|
Maximum ON/OFF cycle |
25 Hz (for pushbutton input) |
|
Maximum current consumption |
500 mA (5 V DC) |
|
Weight |
Approx. 0.30 kg |
|
External connection |
Pressure clamp terminal, Dedicated cable (AKB331), MIL connector cable |
YOKOGAWA ADV151-P53 S2 is a 32-channel digital input module used in Yokogawa Electric Corporation CENTUM VP / CS 3000 DCS systems. It provides reliable 24V DC signal acquisition, high-speed response, and stable operation for industrial automation and process control applications.
Oil & Gas process control systems
Petrochemical and chemical plant automation
Power generation monitoring systems
Manufacturing production line signal acquisition
Building automation (HVAC, safety interlock systems)
Water treatment and utility control systems
32-channel high-density digital input design
24V DC sink/source compatible input
Fast response time (approx. 8 ms)
High isolation withstand voltage up to 2 kV AC
Compact FIO module design for CENTUM systems
Supports harsh industrial environments (wide temperature range)
ON/OFF status signal detection
Field device state monitoring (switches, sensors)
SOE (Sequence of Events) data acquisition
Pushbutton input pulse counting function
Signal isolation and stable transmission to DCS CPU
Real-time process input data communication to CENTUM controller
|
|
Description |
|
|
Model |
ADV151 |
Digital Input Module (32-channel, 24 V DC, Isolated) |
|
Suffix Codes |
-P |
With pushbutton input |
|
|
-E |
With SOE capture (*1) |
|
|
5 |
Without status display; with no explosion protection |
|
|
6 |
With status display; with no explosion protection |
|
|
E |
Without status display; with explosion protection |
|
|
F |
With status display; with explosion protection |
|
|
0 |
Basic type |
|
|
3 |
With ISA Standard G3 option and temperature (-20 to 70 °C) option |
|
Option Codes |
/D5A00 |
With KS Cable Interface Adapter for 32-channel digital [Model: ATD5A-00] |
|
|
/B5S00 |
With Pressure Clamp Terminal Block for Digital Input [Model: ATB5S-00] |
