Honeywell MC-TDIY22 51204160-175 24 Vdc Digital Input with compression terminals Original new, China Honeywell MC-TDIY22 51204160-175 24 Vdc Digital Input with compression terminals Original new Manufacturers, Suppliers, Factory

Overview

Brand Name:	Honeywell
Model Number:	MC-TDIY22 51204160-175
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Description
Product Model	MC-TDIY22
Part Number	80366180-150 / 80366180-175
Input Type	Digital Input
Input Voltage	24 Vdc
Terminal Type	Compression terminals
Channel Type	Multi-channel DI module
Signal Compatibility	Dry contact / voltage input
Isolation	Channel-to-system isolation
Power Consumption	Low power design
Operating Temperature	-20°C to +60°C
Storage Temperature	-40°C to +85°C
Humidity	5%–95% non-condensing
Dimensions	160 mm × 120 mm × 35 mm
Weight	Approx. 0.65 kg
Mounting Type	Rack-mounted I/O card

Description

MC-TDIY22 80366180-150 / 80366180-175is a 24 Vdc digital input module designed for reliable signal acquisition in industrial automation and process control environments. It is engineered to ensure stable performance when collecting discrete field signals from switches, sensors, and control devices, supporting accurate system monitoring and fast response operation.

TheMC-TDIY22series, including variants such asMC-TDIY62in the same product family, is built with compression terminal design to enhance wiring stability and reduce installation time. Its robust construction supports consistent operation in electrically noisy and demanding industrial settings.

As part of the Honeywell-compatible I/O module lineup,MC-TDIY22integrates seamlessly into distributed control systems, helping improve data reliability, system uptime, and overall control efficiency across large-scale automation architectures.

Applications

Power plants: Used for generator set status monitoring and relay protection.
Substations: Enable bus differential control, line protection, and switchyard signal acquisition.
Chemical plants: Integrate process control automation and intrinsically safe signal monitoring.
Steel mills (metallurgical plants): Perform equipment logic control in high-temperature and EMI-heavy environments.
Machinery manufacturing plants: Used for automated production lines, robotic stations, and packaging control systems.

Features

Stable 24 Vdc digital signal acquisition
Compression terminal design for secure wiring
High immunity to industrial electrical noise
Modular design for easy system integration
Supports multi-channel input processing
Compact structure for cabinet optimization
Reliable long-term industrial operation

Functions

Collects discrete field status signals
Converts input signals into system-readable data
Supports real-time monitoring and control logic
Ensures accurate signal transmission to controller
Enhances system diagnostics and reliability

FAQ

Q1: What is MC-TDIY22 used for?
A1: It is used for collecting 24 Vdc digital signals in industrial automation systems.

Q2: What type of terminals does MC-TDIY22 use?
A2: It uses compression terminals for stable and secure wiring connections.

Q3: Is MC-TDIY22 suitable for harsh environments?
A3: Yes, it is designed for industrial environments with electrical noise and temperature variation.

Q4: Can MC-TDIY22 integrate with control systems?
A4: Yes, it integrates with distributed control systems for real-time signal processing.

Q5: What signals can MC-TDIY22 handle?
A5: It supports standard 24 Vdc discrete signals from switches and field sensors.

Spares

Number	Describe
MC-TDIA62	51304431-250 / 51304431-275 — 240 Vac Digital Input with fixed-screw terminals
MC-TDID12	51304441-150 / 51304441-175 — 24 Vdc Digital Input with compression terminals
MC-TDID52	51304441-250 / 51304441-275 — 24 Vdc Digital Input with fixed-screw terminals
MC-TDID72	51303928-150 — 24 Vdc Digital Input with removable-screw terminals
MC-TDIY22	80366180-150 / 80366180-175 — 24 Vdc Digital Input with compression terminals
MC-TDIY62	80366180-250 / 80366180-275 — 24 Vdc Digital Input with fixed-screw terminals
MC-TDOA13	51304648-150 / 51304648-175 — 120/240 Vac Solid-State Digital Output with compression terminals
MC-TDOA53	51304648-250 / 51304648-275 — 120/240 Vac Solid-State Digital Output with screw terminals
MC-TDOD13	51304650-150 — 3-30 Vdc Digital Output with compression terminals
MC-TDOD14	51309153-175 — 3-30 Vdc Digital Output with compression terminals
MC-TDOD22	51304428-150 — 31-200 Vdc Digital Output with compression terminals
MC-TDOD23	51309154-175 — 31-200 Vdc Digital Output with compression terminals
MC-TDOD53	51304650-250 — 3-30 Vdc Digital Output with screw terminals
MC-TDOD54	51309153-275 — 3-30 Vdc Digital Output with screw terminals
MC-TDOD62	51304428-250 — 31-200 Vdc Digital Output with screw terminals
MC-TDOD63	51309154-275 — 31-200 Vdc Digital Output with screw terminals
MC-TDON12	51304446-150 — 24 Vdc Nonisolated Digital Output with compression terminals
MC-TDON52	51304446-250 — 24 Vdc Nonisolated Digital Output with screw terminals
MC-TDOY22	80366183-150 / 80366183-175 — 24 Vdc Isolated Digital Output with compression terminals
MC-TDOY62	80364013-150 / 80364013-175 — 24 Vdc Isolated Digital Output with screw terminals
