Bently Nevada 330104-15-23-10-02-00 3300 XL 8 mm Probe Original new, China Bently Nevada 330104-15-23-10-02-00 3300 XL 8 mm Probe Original new Manufacturers, Suppliers, Factory

Overview

Brand Name:	Bently Nevada
Model Number:	330104-15-23-10-02-00
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Specification
Model	330104-15-23-10-02-00
System Type	3300 XL 8 mm Proximity Probe
Thread Type	M10 x 1
Total Length	1.5 m (system dependent)
Cable Type	75Ω triaxial FEP insulated
Connector Type	ClickLoc coaxial connector
Material	Stainless steel (AISI 303/304)
Tip Material	Polyphenylene sulfide (PPS)
Operating Temp	-52°C to +177°C
Storage Temp	-52°C to +177°C
Weight	~323 g/m (probe)

Description

The330104-15-23-10-02-00proximity probe is part of the advanced Bently Nevada 3300 XL 8 mm transducer family, engineered for precise vibration and position monitoring in rotating machinery. Designed to work seamlessly with3300 XL Proximitor Sensorand compatible extension cables, it delivers stable eddy-current measurement performance for industrial monitoring systems.

Built for harsh environments, the330104-15-23-10-02-00probe ensures high accuracy in both static and dynamic measurements, making it ideal for turbines, compressors, pumps, and motor-driven equipment. Its robust stainless-steel construction and PPS tip enhance durability and long-term operational reliability.

With full interchangeability across the 3300 XL series, including330103and other 8 mm probe variants, this model supports flexible installation and reduced maintenance complexity. It is widely used in predictive maintenance and machinery protection systems across critical industries.

Applications

Power plants: Used for generator set vibration monitoring, shaft displacement measurement, and relay protection systems.
Substations: Enables bus differential protection, line fault detection, and switchgear condition monitoring.
Chemical plants: Supports process automation systems with intrinsically safe vibration and position measurement.
Steel mills (metallurgical plants): Ensures stable machine control under high temperature and strong electromagnetic interference conditions.
Machinery manufacturing plants: Applied in automated production lines, robotics systems, and packaging equipment for real-time monitoring and control.

Features

High-precision eddy current sensing for vibration and position measurement
Rugged stainless-steel probe body for industrial durability
PPS molded tip improves mechanical strength and wear resistance
ClickLoc connector ensures fast, secure, and tool-free installation
Compatible with 3300 XL system for full interchangeability
FluidLoc option reduces risk of oil leakage in harsh machinery environments
High EMI/RFI immunity for stable signal output
Suitable for confined installation spaces in OEM machinery designs

Functions

Measures shaft vibration and radial displacement in rotating machinery
Provides real-time position feedback for condition monitoring systems
Works with Proximitor sensor to convert distance into voltage signal
Supports predictive maintenance by detecting early mechanical faults
Enables machinery protection through continuous monitoring output
Delivers reliable signal transmission in high-noise industrial environments
Maintains consistent performance across temperature and pressure variations
Integrates into PLC and DCS systems for automated control logic

FAQ

Q1: What is the 330104-15-23-10-02-00 used for?
A1: It is used for vibration and shaft position monitoring in rotating industrial machinery.

Q2: Is it compatible with other 3300 XL systems?
A2: Yes, it is fully compatible and interchangeable with other Bently Nevada 3300 XL probes and sensors.

Q3: Can it work in harsh environments?
A3: Yes, it is designed for high temperature, high vibration, and industrial EMI conditions.

Q4: What type of signal does it produce?
A4: It provides an eddy-current-based analog signal used by Proximitor sensors.

Q5: Does it support predictive maintenance systems?
A5: Yes, it is widely used in condition monitoring and predictive maintenance applications.

Spares

Number	Description
148722-01	3300 XL test plug with 3-pin adapter, color-coded 1-meter wires, and banana plug termination for Proximitor sensor testing without removing field wiring.
04310310	3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread forming screw, 4 required per sensor (standard mounting hardware).
03200006	Silicone self-fusing tape, 9.1-meter roll for electrical insulation and environmental protection of connectors.
40113-02	Connector Protector Kit for 3300 XL 8 mm probes and extension cables, including installation tools and protective accessories.
136536-01	Connector protector adapter for compatibility with pre-1998 installation tools used on 75Ω ClickLoc connectors.
40180-02	Connector protectors package containing 10 pairs for environmental sealing of 3300 XL probe and extension cable connectors.
03839410	75Ω triaxial male connector protector for extension cable side, ensuring sealed connection to female protector on probe.
03839420	75Ω triaxial female connector protector for probe side or Proximitor sensor connection protection against environmental exposure.
04301007	3/8-24 probe lock nut with dual safety wire holes for secure mechanical fixation of proximity probes.
04301008	M10 x 1 probe lock nut with safety wire holes for secure installation of proximity probes in industrial applications.
330153-01	3300 XL connector kit including ClickLoc male/female connectors, sleeves, FEP tubing, and silicone tape for probe and cable assembly.
