Honeywell TC-OAV081 Series C Analog Output Module (HART) Original new, China Honeywell TC-OAV081 Series C Analog Output Module (HART) Original new Manufacturers, Suppliers, Factory

Overview

Brand Name:	Honeywell
Model Number:	TC-OAV081
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Description	Value
Model	TC-OAV081
Type	Analog Output Module (Series A CIOM-A)
Channels	8-point output
Signal Type	Current / Voltage (non-isolated)
Terminal Block	20-pin removable (TC-TBCH compatible)
Power Supply	24 VDC backplane supply
Communication	ControlNet via CNI interface
Mounting Type	DIN rail chassis mounted
Dimension	3.5x14x14.5cm
Weight	0.24kg

Description

The TC-OAV081 is a Series-A analog output module engineered for distributed industrial automation systems requiring stable voltage and current signal control. It is designed as part of Honeywell’s CIOM-A chassis platform, supporting seamless integration with C200E-based architectures and ControlNet communication networks.

In addition to the main model TC-OAV081 (51309288-225), it is compatible within the same Series-A family alongside modules such as TC-OAH061, TC-IAH161, and TK-OAV081, enabling flexible system expansion and mixed I/O configurations in both redundant and non-redundant setups.

Built for high-density process control applications, the module ensures reliable analog output performance in demanding industrial environments, while maintaining compatibility with DIN-rail chassis systems and remote I/O termination architectures.

Applications

Power plants: Used for generator control output, load regulation, and relay coordination systems
Substations: Enables voltage regulation, switching control, and protection signal output
Chemical plants: Supports process automation, flow control, and safe analog signal distribution
Steel mills: Provides stable control output in high-temperature and EMI-heavy environments
Machinery manufacturing plants: Applied in robotics, conveyor systems, and automated production lines

Features

8-channel analog output architecture for compact system design
High stability signal transmission for industrial control loops
Compatible with Series-A CIOM chassis platform
Supports flexible integration with ControlNet-based systems
DIN-rail mountable design for easy installation and maintenance

Functions

Converts digital control signals into precise analog outputs
Supports process regulation in continuous industrial operations
Enables distributed I/O architecture in remote chassis systems
Works with redundant or non-redundant controller environments
Provides reliable output control for industrial automation loops

FAQ

Q1: What is TC-OAV081 used for?
A1: It is used for analog output control in industrial automation systems such as process plants and manufacturing lines.

Q2: How many output channels does it support?
A2: It provides 8 analog output channels for voltage or current signals.

Q3: Is TC-OAV081 compatible with ControlNet systems?
A3: Yes, it operates through the ControlNet interface using CNI modules.

Q4: Can it be used in harsh environments?
A4: Yes, it is designed for stable operation in high EMI and industrial conditions.

Q5: Does it support chassis-based installation?
A5: Yes, it is fully compatible with Series-A CIOM DIN-rail chassis platforms.

Spares

Number	Describe
TC-FFPCX1	24 VDC (1.3 Amp) Power Supply
TC-FIDA81	120 VAC Digital Input, 8 Channels
TC-FODA81	120 VAC Digital Output, 8 Channels
TC-FID161	24 VDC Sink Digital Input, 16 Channels
TC-FOD161	24 VDC Source Digital Output - Protected, 16 Channels
TC-FID321	24 VDC Sink Digital Input, 32 Channels
TC-FOD321	24 VDC Source Digital Output - Protected, 32 Channels
TC-FIAH81	High Level Analog Input, 8 Channels
TC-FIA121	High Level Analog Input, 12 Channels
TC-FOA041	Analog Output, 4 Channels
TC-FOA121	Analog Output, 12 Channels
TC-FIR081	3-Wire RTD Analog Input, 8 Channels
TC-FIL081	Thermocouple Analog Input, 8 Channels
TC-FOR081	Relay Digital Output, 8 Channels
TC-FCCN01	ControlNet Gateway, Non-Redundant Media
TC-FCCR01	ControlNet Gateway, Redundant Media
TC-FTB301	3-Wire Terminal Base
TC-FTB3T1	3-Wire Temperature Terminal Base
9900-CE1	Terminal Base Extender Cable, 1 FT
9900-CE3	Terminal Base Extender Cable, 3 FT
