Product Name:TU818 Compact Module Termination Unit
Brand Name:ABB
Model Number:TU818V1 3BSE069209R1
Country of Origin:Sweden
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
ABB |
Model Number: |
TU818V1 3BSE069209R1 |
Country of Origin: |
Sweden |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Product Model | TU818V1 |
| Product ID | 3BSE069209R1 |
| Product Type | Module Termination Unit (MTU) |
| System Series | ABB S800 I/O |
| I/O Voltage (DC) | 50 V |
| Terminal Configuration | 1x32 or 2x16 signal terminals |
| Function | Signal Termination & Field Wiring Interface |
| Mounting Type | DIN Rail / Cabinet Installation |
| Country of Origin | Bulgaria |
| Customs Tariff Number | 85389091 |
| Net Weight | 0.26 kg |
| Gross Volume | 0.001 m³ |
| Dimensions (Approx.) | 170 × 85 × 60 mm |
| Operating Environment | Industrial Control Systems |
The TU818V1 (3BSE069209R1) Compact Module Termination Unit is a high-reliability ABB S800 I/O interface component designed to simplify signal wiring and improve connection stability within distributed control systems. It provides secure termination points for field signals, ensuring efficient integration between process instrumentation and control modules.
Engineered for use in ABB 800xA and Advant-based automation platforms, the TU818V1 supports structured signal distribution with 1x32 or 2x16 terminal configurations. Its compact design improves cabinet organization while maintaining high signal integrity for industrial I/O communication.
As part of ABB’s S800 I/O family, the 3BSE069209R1 TU818V1 is widely used in modernization and expansion projects where reliable field connection, easy maintenance, and stable control system performance are required.
Power Plants: Used for signal termination in generator monitoring systems, turbine control, and protection relay wiring connections.
Substations: Supports bus differential protection systems, switchgear signal distribution, and substation automation wiring interfaces.
Chemical Plants: Enables safe and organized field signal connection for process instrumentation and control systems.
Steel Mills: Provides reliable terminal connections for equipment operating under high temperature, vibration, and electrical noise conditions.
Machinery Manufacturing Plants: Applied in automated production lines, robotics systems, and industrial control panels requiring structured I/O wiring.
High-Density Terminal Design: Supports up to 32 signal connections in a compact layout.
Reliable Signal Termination: Ensures stable and secure field wiring connections.
ABB S800 Compatibility: Designed for seamless integration with ABB 800xA systems.
Compact Structure: Optimized for space-saving installation in control cabinets.
Maintenance-Friendly Layout: Simplifies wiring inspection and system servicing.
Industrial Durability: Suitable for long-term operation in harsh environments.
Signal Termination: Provides secure connection points for field wiring.
I/O Signal Distribution: Organizes and routes signals to control modules.
System Integration Support: Connects field devices with ABB S800 I/O systems.
Wiring Simplification: Reduces installation complexity in control cabinets.
Maintenance Facilitation: Improves accessibility for testing and replacement tasks.
Q1: What is the main function of the TU818V1 module?
A1: It serves as a termination unit for organizing and connecting field signals in ABB S800 I/O systems.
Q2: Is TU818V1 compatible with ABB 800xA systems?
A2: Yes, it is fully compatible with ABB 800xA and S800 I/O architectures.
Q3: How many terminals does the TU818V1 support?
A3: It supports 1x32 or 2x16 signal terminal configurations.
Q4: What is the main application of this MTU?
A4: It is used for field signal wiring in industrial automation and control systems.
Q5: Is TU818V1 suitable for retrofit projects?
A5: Yes, it is widely used in system expansion and modernization applications.
|
