Allen-Bradley 1746-IN16 16-Point AC/DC Input Module

Allen-Bradley 1746-IN16 16-Point AC/DC Input Module

Product Name: 16-Point AC/DC Input Module

Brand Name: Allen-Bradley

Model Number: 1746-IN16

Place of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

Overview
Specifications
Commercial Terms
Description
Function
About Company
Why Choose Us
Other Brand
Recommended Products

Contact Info

Sales	Email	Phone/Whatsapp
Jim Pei	[email protected]	+86 18020776782

Specifications

Product Name	Allen-Bradley 1746-IN16 16-Point AC/DC Input Module
Manufacturer	Allen-Bradley
Product Type	16-Point AC/DC Input Module
Part Number	1746-IN16
Place of shipment	Xiamen, China
Country of origin	USA
Product Family	SLC 500
I/O Type	Input
Voltage Category	24V AC/DC
Operating Voltage – DC	10–30V DC Sink
Operating Voltage – AC	10–30V AC at 47–63 Hz
Number of Inputs	16
Points per Common	16
Backplane Current Draw @ 5V DC	0.085 A
Backplane Current Draw @ 24V DC	0.0 A
Signal Delay – DC	On = 15 ms max.; Off = 15 ms max.
Signal Delay – AC	On = 25 ms max.; Off = 25 ms max.
Off-State Voltage – DC	3V DC max.
Off-State Voltage – AC	3V AC max.
Off-State Current – DC	1 mA DC max.
Off-State Current – AC	1 mA AC max.
Nominal Input Current – DC	8 mA at 24V DC
Nominal Input Current – AC	8 mA at 24V AC
Inrush Current	0.02 A max. (AC only)
Input Configuration	24V AC/DC Sinking
Removable Terminal Block	Yes (RTB)
Watts per Point	0.35 W
Minimum Power Dissipation	0.425 W
Total Power Dissipation	6.00 W

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Description

The Allen-Bradley 1746-IN16 is a 16-Point AC/DC Input Module designed for SLC 500 PLC and industrial automation systems. It provides 16 sinking input points and supports both AC and DC field signals, enabling reliable monitoring of sensors, switches, pushbuttons, limit switches, and other discrete devices. The Allen-Bradley 1746-IN16 is well suited for machine automation, manufacturing, process control, material handling, SLC 500 I/O expansion, PLC maintenance, and legacy automation replacement applications.

Function

The Allen-Bradley 1746-IN16 SLC 500 Input Module provides discrete signal acquisition for compatible PLC-based industrial automation and machine control systems.
Receives input signals from field devices such as sensors, switches, pushbuttons, limit switches, relays, and other compatible discrete equipment.
Supports both AC and DC input signals, providing flexibility for automation systems containing different types of field devices.
Transfers field input status to the SLC 500 processor, allowing PLC programs to make control decisions based on real-time machine and process conditions.
Enables monitoring of equipment states, operator commands, safety-related status signals, and production process conditions within compatible applications.
Helps centralize multiple field inputs within the SLC 500 architecture, simplifying signal management and industrial control system organization.
Removable terminal block design supports convenient field wiring, module servicing, troubleshooting, and replacement during system maintenance.
The 1746-IN16 is particularly suitable for SLC 500 I/O expansion, machine automation, manufacturing, process control, PLC repair, input module replacement, and continued support of legacy Allen-Bradley systems.
