Allen-Bradley 1746-ITV16 high-speed digital DC sourcing input module Ready For Ship

Allen-Bradley 1746-ITV16 high-speed digital DC sourcing input module Ready For Ship

Product Name:digital DC sourcing input module

Brand Name:Allen-Bradley

Model Number:1746-ITV16

Country of Origin:USA

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

allen bradley 1746 itv16 high speed digital dc sourcing input module ready for ship-1

Overview
How to get price
Specifications
Description
Applications
Environment and Certification
High-Resolution Measurement
FAQ
Spares
Recommended Products

Overview

Brand Name:	Allen-Bradley
Model Number:	1746-ITV16
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

How to get price

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Manufacturer	Allen-Bradley by Rockwell Automation
Product Model	1746-ITV16 Fast-Response Digital DC Sourcing Input Module
Product Series	SLC 500 Modular I/O
Number of Inputs	16 sourcing digital input channels, 16 points per common
Input Voltage	24 VDC nominal, operating range 10…30 VDC
Input Current	8 mA nominal at 24 VDC
Off-State Voltage	5.0 VDC maximum
Off-State Current	1.5 mA maximum
Signal Response Time	ON ≤0.30 ms, OFF ≤0.50 ms
Backplane Current	85 mA @ 5V DC, 0 mA @ 24V DC
Thermal Dissipation	3.63 W maximum
Compatibility	SLC 500 processors, compatible with 1746-SIM input simulator
Mounting Method	Standard 1746 SLC chassis, removable terminal block
Dimensions	Approx. 145 × 35 × 142 mm (5.7 × 1.4 × 5.6 in.)
Weight	Approx. 0.23 kg (0.51 lb)

Description

The Allen-Bradley 1746-ITV16 is a high-speed digital DC sourcing input module developed for the SLC 500 programmable controller platform. Designed for fast signal acquisition in time-critical automation systems, 1746-ITV16 delivers reliable 24 VDC input processing with exceptionally short response times. It is an ideal choice for production lines, packaging equipment, and high-speed machine control where accurate event detection is essential.

Compatible with SLC 5/03, SLC 5/04, and SLC 5/05 controllers, the 1746-ITV16 features 16 sourcing input channels with a shared common, removable terminal block support, and stable backplane communication. It integrates seamlessly with other SLC 500 I/O modules such as 1746-IV16, 1746-IB16, and 1746-IN16, providing flexible system expansion.

Engineered for long-term industrial reliability, the 1746-ITV16 minimizes input latency while maintaining dependable operation in demanding factory environments. Its compact design, fast response capability, and compatibility with standard SLC hardware make it an excellent solution for OEM machinery, automated manufacturing, material handling, and industrial process control.

Applications

Power plants: Capture high-speed digital status signals from turbines, switchgear, and auxiliary equipment for dependable automation.
Substations: Process fast protection and monitoring inputs from circuit breakers, relays, and field instrumentation.
Chemical plants: Collect rapid process signals from sensors and safety interlocks in continuous production systems.
Steel mills: Support high-speed machine sequencing, conveyor monitoring, and harsh industrial process automation.
Machinery manufacturing: Integrate with robotic cells, CNC equipment, packaging machines, and automated assembly lines.
Material handling systems: Detect conveyor positions, photoelectric sensors, and limit switches with minimal response delay.

Environment and Certification

Supports continuous operation in demanding industrial automation environments with stable digital signal acquisition.
Designed for installation in standard Allen-Bradley SLC 500 modular control cabinets.
Fast-response circuitry minimizes input latency for time-critical machine control applications.
High electrical noise immunity helps maintain reliable performance near motors, drives, and switching equipment.
Compatible with removable terminal blocks for simplified installation and maintenance.
Engineered for long operating life with durable industrial-grade electronic components.
Suitable for integration into manufacturing, utility, and process automation systems requiring dependable digital inputs.
Designed to operate alongside other SLC 500 digital and analog I/O modules for scalable system architectures.

High-Resolution Measurement

Provides accurate detection of proximity switches, photoelectric sensors, and encoder-generated pulse signals.
Reduces missed events during high-speed production and packaging processes.
Maintains stable signal integrity across 16 independent sourcing input channels.
Optimized for precision machine sequencing and real-time automation control.
Supports reliable synchronization with high-speed PLC logic execution.
Helps improve production accuracy by minimizing input processing delays.
Suitable for automation systems requiring deterministic digital signal acquisition.

FAQ

Q1: What is the 1746-ITV16 used for?
A1: It is a fast-response 24 VDC sourcing digital input module designed for Allen-Bradley SLC 500 PLC systems.

Q2: How many input channels does the 1746-ITV16 provide?
A2: The module offers 16 independent digital sourcing input channels with one common group.

Q3: Which PLC processors support the 1746-ITV16?
A3: It is compatible with the Allen-Bradley SLC 500 family, including SLC 5/03, SLC 5/04, and SLC 5/05 controllers.

Q4: What is the response time of the 1746-ITV16?
A4: The module provides fast signal processing with a maximum ON delay of 0.30 ms and OFF delay of 0.50 ms.

Q5: Can the 1746-ITV16 work with the 1746-SIM input simulator?
A5: Yes. It is fully compatible with the 1746-SIM input simulator for convenient testing and commissioning of SLC 500 control systems.
