Product Name: ControlNet RS-232 Interface Module
Brand Name: Allen-Bradley
Model Number: 1747-KFC15
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
Phone/Whatsapp |
|
Jim Pei |
| Product Name | Allen-Bradley 1747-KFC15 ControlNet RS-232 Interface Module |
| Manufacturer | Allen-Bradley |
| Product Type | ControlNet RS-232 Interface Module |
| Part Number | 1747-KFC15 |
| Weight | 0.22kg |
| Estimated shipping dimensions | 3.5x13.3x17.5cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Series | A |
| Catalog Revision | B01 |
| Firmware Revision | 1.7 |
| Backplane Power | 5.25 VDC @ 640 mA |
| Serial Interface | RS-232C |
| Serial Protocol | DF1 Protocol |
| Network Interface | ControlNet. |
| ControlNet Compatibility | Compatible with devices that comply with the ControlNet specification |
| Network Access Port | ControlNet Network Access Port (NAP) |
| NAP Compatibility | Compatible with programming terminal products that comply with ControlNet NAP specifications |
| RS-232 Operating Modes | DF1 Full-duplex / Half-duplex communication |
| Supplied Cable | RS-232 cable |
| Hazardous Location Rating | Class I, Division 2 |
| Hazardous Location Groups | Groups A, B, C, D |
| Temperature Code | T4A |
| Certifications / Markings | UL, CSA, CE |
| Primary Function | Provides an RS-232 interface to a ControlNet network for SLC 500 applications |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The Allen-Bradley 1747-KFC15 is a ControlNet RS-232 Interface Module designed to provide reliable communication between RS-232 devices and ControlNet networks in SLC 500 automation systems. Supporting DF1 Full-duplex and Half-duplex communication, the module enables industrial controllers, programming equipment, and compatible serial devices to access ControlNet-based applications. With an integrated ControlNet Network Access Port (NAP), industrial certifications, and Class I, Division 2 hazardous-location capability, the Allen-Bradley 1747-KFC15 is well suited for factory automation, process control, system integration, maintenance, and legacy SLC 500 communication applications.
Q1: What is the Allen-Bradley 1747-KFC15 ControlNet RS-232 Interface Module?
The 1747-KFC15 is an industrial communication module that provides an RS-232 interface to a ControlNet network for compatible Allen-Bradley SLC 500 applications.
Q2: How does the 1747-KFC15 connect RS-232 devices to ControlNet?
It bridges RS-232 serial communication with the ControlNet network, allowing compatible serial equipment and controllers to exchange data across the automation system.
Q3: Which serial protocol is supported by the Allen-Bradley 1747-KFC15?
The module supports the DF1 protocol with both Full-duplex and Half-duplex communication modes.
Q4: Does the 1747-KFC15 include a ControlNet Network Access Port?
Yes. The 1747-KFC15 includes a ControlNet NAP for connection with compatible programming terminals and other products that comply with ControlNet NAP specifications.
Q5: Can the 1747-KFC15 be used in hazardous industrial locations?
Yes. The 1747-KFC15 is rated for specified Class I, Division 2, Groups A, B, C, and D locations with a T4A temperature code when installed according to applicable requirements.
Q6: Why use the 1747-KFC15 in an existing SLC 500 system?
The 1747-KFC15 provides a practical way to retain RS-232/DF1 equipment while integrating it with an established ControlNet architecture, making it useful for maintenance, replacement, system expansion, and legacy automation support.
