Product Name:3300 5mm Proximity Probes
Brand Name:BENTLY NEVADA
Model Number:330171-08-24-10-02-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330171-08-24-10-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Description |
|---|---|
| Model | 330171-08-24-10-02-00 |
| Product Type | 3300 5mm Proximity Probe |
| Thread Type | 1/4-28 UNF |
| Probe Diameter | 5 mm |
| Total Cable Length | 2.0 m (configurable option) |
| Connector Type | Miniature ClickLoc coaxial connector |
| Cable Type | 75Ω triaxial, shielded |
| Unthreaded Length | Configurable (0.0–8.8 in range) |
| Weight | Approx. 0.32–0.35 kg (probe only typical) |
| Material | Stainless steel (AISI 303/304) |
| Dimension | Standard compact probe body, industrial fit |
The330171-08-24-10-02-003300 5mm Proximity Probe is part of the high-precision eddy current measurement system designed for vibration and position monitoring in rotating machinery. It delivers stable, non-contact sensing performance for critical industrial environments where reliability and accuracy are essential.
Built on the3300 5mm series, including models like330171and330172, this probe works with XL extension cables and Proximitor sensors to provide proportional voltage output based on target distance. It supports both static and dynamic measurement applications in turbines, compressors, and motor-driven systems.
With rugged stainless-steel construction and ClickLoc connector technology, the330171-08-24-10-02-00ensures secure installation, strong environmental resistance, and long service life. It is ideal for compact installations where smaller probe geometry is required without compromising measurement performance.
Q1: What is the 330171-08-24-10-02-00 used for?
A1: It is used for non-contact vibration and position measurement in rotating machinery systems.
Q2: Is it compatible with other 3300 series components?
A2: Yes, it works with 3300 XL extension cables and Proximitor sensors.
Q3: Can it be used in harsh industrial environments?
A3: Yes, it is designed for high temperature, vibration, and EMI-heavy conditions.
Q4: What type of signal output does it provide?
A4: It provides a voltage output proportional to the distance from the target surface.
Q5: Does it require special installation tools?
A5: No, ClickLoc connectors allow tool-free, finger-tight installation.
| Number | Description |
|---|---|
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor twisted shielded cable used for Proximitor Sensor to monitor connections. |
| 03200006 | Silicone self-fusing tape, 9.1 m (10 yard) roll for connector protection, providing insulation and environmental sealing. Not recommended inside machine casing. |
| 40113-03 | Connector Protector Kit for 3300 5mm probes, including connector protectors and installation tools. |
| 136536-01 | Connector Protector Adapter, enables compatibility of pre-1998 connector protector kits with ClickLoc extension cable connectors. |
| 40180-03 | Connector Protectors package, contains 10 pairs of 75Ω coaxial connector protection sets for environmental sealing. |
| 03839410 | 75Ω triaxial / 95Ω coaxial male connector protector, installed on extension cable to protect probe connections from environmental exposure. |
| 03800001 | 75Ω coaxial female connector protector, installed on 3300 5mm probe lead to ensure sealed connection with extension cable protector. |
| 163356 | Connector Crimp Tool Kit including multi-connector inserts and installation instructions; compatible with 330153 connector kits and ClickLoc systems. |
