Product Name: CompactBlock Output Module
Brand Name: Allen-Bradley
Model Number: 1791D-0B8P
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
| Product Name | Allen-Bradley 1791D-0B8P CompactBlock Output Module |
| Manufacturer | Allen-Bradley |
| Product Type | CompactBlock Output Module |
| Part Number | 1791D-0B8P |
| Weight | 0.18 kg |
| Estimated shipping dimensions | 14.7x5.2x3.8cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Outputs per Block | 8 |
| On-state Voltage Range | 10 - 30V dc |
| On-state Voltage Drop | 0.5V dc @ rated current |
| On-state Current | 0.5A maximum |
| Off-state Leakage | 1.0mA maximum |
| Module Current (all outputs) | 4.0A maximum |
| Surge Current - for 10ms, repeatable every 2 s | 1.0A maximum |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| DeviceNet Power Voltage | 11V - 25 V dc |
| DeviceNet Power Current | 200mA maximum (with expansion) |
| Auxiliary Power Voltage | 10 - 30V dc |
| Auxiliary Power Current | 4A maximum |
| Enclosure | IEC IP20 |
The Allen-Bradley 1791D-0B8P CompactBlock Output Module is a DeviceNet-based compact digital output module designed for distributed industrial control applications. It provides 8 digital DC output channels for controlling actuators, indicators, relays, and other field devices. With a 10–30 VDC operating voltage range, high current handling capability, and compact IP20 housing, the module enables flexible installation and efficient field-level control while reducing wiring complexity in automation systems.
Provides 8 digital DC output channels for controlling field devices.
Converts DeviceNet control commands into discrete output signals.
Supplies switching control for actuators, valves, indicators, and other DC loads.
Supports auxiliary power connection for field device operation.
Enables decentralized I/O installation close to machines and equipment.
Provides output protection features to improve system reliability.
Compared with traditional centralized output modules, the Allen-Bradley 1791D-0B8P offers a compact distributed design, simplified wiring, and reliable DeviceNet communication, making it suitable for flexible industrial automation applications.
