HONEYWELL TC-IDA161 120 VAC 16-Point Discrete Input Module Ready For Ship, China HONEYWELL TC-IDA161 120 VAC 16-Point Discrete Input Module Ready For Ship Manufacturers, Suppliers, Factory

Overview

Brand Name:	Honeywell
Model Number:	TC-IDA161
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Description
Model	TC-IDA161
Type	120 VAC Discrete Input Module
Channels	16 inputs (8 points per common)
Nominal Voltage	120 VAC
Operating Range	79–132 VAC, 47–63 Hz
Off-State Voltage	≤ 20 VAC
Input Current	5 mA min @ 79 VAC
Power Dissipation	6.0 W max
Isolation	2546 VDC tested (channel/system)
Terminal Block	TC-TBNH (20-pin)
Dimension	165 × 150 × 150 mm
Weight	~1.5 kg

Description

The TC-IDA161 (also known as TK-IDA161) is a 16-channel 120 VAC discrete input module designed for Experion Series-A CIOM-A chassis systems. It is engineered for reliable signal acquisition in industrial automation environments, supporting high-density input monitoring with stable electrical isolation and fast response performance.

This module is part of Honeywell’s chassis-based I/O architecture and operates seamlessly with the C200E control processor over ControlNet communication. It is typically installed in Series-A remote I/O chassis and used alongside compatible terminal blocks such as TC-TBNH, ensuring flexible field wiring and simplified maintenance.

As part of the Honeywell modular I/O family, the TC-IDA161 supports redundant and non-redundant system configurations, making it suitable for critical process control applications requiring high reliability, electrical stability, and efficient channel organization.

Applications

Power plants: generator monitoring and relay protection
Substations: bus protection, line monitoring, switching signals
Chemical plants: process automation and safe signal isolation
Steel mills: harsh environment control with EMI resistance
Machinery manufacturing: automated production line control

Features

16-channel high-density input design
Stable 120 VAC industrial compatibility
Strong electrical isolation protection
Chassis-based modular installation
Compatible with Series-A CIOM architecture

Functions

Digital signal acquisition from field devices
Status monitoring of switches and contacts
Integration with C200E control systems
Fast response input processing
Reliable data transmission via ControlNet

FAQ

Q1: What is the TC-IDA161 used for?
A1: It is used for 120 VAC discrete signal acquisition in industrial automation systems.

Q2: How many input channels does TC-IDA161 support?
A2: It supports 16 input channels with 8 points per common.

Q3: Is TC-IDA161 compatible with C200E controllers?
A3: Yes, it fully supports C200E-based Experion Series-A systems.

Q4: What wiring terminal block is required?
A4: It uses TC-TBNH 20-pin terminal blocks for field wiring.

Q5: Can TC-IDA161 be used in harsh environments?
A5: Yes, it is designed for industrial environments with electrical isolation and stable performance.

Spares

number	describe
IAH061	High Level Analog Input, 10V & 4–20mA, 6 channels, 20-pin TB
OAH061	Analog Output, 4–20mA, 6 channels, 20-pin TB
OAV061	Analog Output, 10V, 6 channels, 20-pin TB
IXL061	Thermocouple Input, 6 channels, 20-pin TB
IXL062	Thermocouple Input, 6 channels, 20-pin TB
IXR061	RTD Input, 6 channels, 20-pin TB
IAH161	Analog Input, Voltage/Current, 16 channels, 36-pin TB
OAV081	Analog Output, Current/Voltage, 8 channels, 20-pin TB
HAI081	Analog Input, Voltage/Current/HART enabled, 8 channels, 36-pin TB
HAO081	Analog Output, Voltage/Current/HART enabled, 8 channels, 20-pin TB
ORC081	Isolated Relay Output, 24–220 VAC, 8 NO + 8 NC, 36-pin TB
ORC161	Isolated Relay Output, 24–220 VAC, 16 NO, 36-pin TB
IDK161	AC Input, 120 VAC isolated, 16 channels, 36-pin TB
IDW161	AC Input, 220 VAC isolated, 16 channels, 36-pin TB
IDX081	AC Input, 120 VAC diagnostic, 8 channels, 20-pin TB
IDA161	AC Input, 120 VAC, 16 channels, 20-pin TB
IDB321	AC Input, 120 VAC, 32 channels, 36-pin TB
ODK161	AC Output, 120/220 VAC isolated, 16 channels, 36-pin TB
ODX081	AC Output, 120 VAC diagnostic, 8 channels, 20-pin TB
ODA161	AC Output, 120/220 VAC, 16 channels, 20-pin TB
IDJ161	DC Input, 24 VDC isolated, 16 channels, 36-pin TB
IDX161	DC Input, 10–30 VDC diagnostic, 16 channels, 36-pin TB
IDD321	DC Input, 24 VDC, 32 channels, 36-pin TB
ODJ161	DC Output, 24 VDC isolated, 16 channels, 36-pin TB
ODX161	DC Output, 10–30 VDC diagnostic, 16 channels, 36-pin TB
ODD321	DC Output, 24 VDC, 32 channels, 36-pin TB
TK-MDP081	High Speed Pulse Input module, 8 counter inputs + 2 outputs, 36-pin TB
TC-TK-MUX021	Serial Interface module, 2 serial channels
TK-PRS021	C200 Control Processor module
TK-PRR021	Redundancy Module for C200 system
SST-PFBCLX	PROFIBUS DP Interface Module
1756-DNB	DeviceNet Bridge Module
TK-IOLI01	I/O Link Module for PMIO interface
TC-CCN014	CNI Single Media Communication Module
TC OR TK-CCR014	CNI Dual Media Communication Module
TK-FTEB01	Ethernet / FTE Bridge Module
