Product Name: Ultra3000 Digital Servo Drive
Brand Name: Allen-Bradley
Model Number: 2098-DSD-020-SE
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
Phone/Whatsapp |
|
Jim Pei |
| Product Name | Allen-Bradley 2098-DSD-020-SE Ultra3000 Digital Servo Drive |
| Manufacturer | Allen-Bradley |
| Product Type | Ultra3000 Digital Servo Drive |
| Part Number | 2098-DSD-020-SE |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Product Series | Ultra3000 |
| Voltage Class | 230 V Class |
| AC Input Voltage | 100–240 Vrms, Single Phase |
| AC Input Frequency | 47–63 Hz |
| Nominal AC Input Current | 18 Arms |
| Maximum Inrush Current | 100 A (0-peak), at 230 VAC Input |
| Continuous Output Current | 10 A (0-peak) |
| Intermittent Output Current | 30 A (0-peak) |
| Bus Capacitance | 1880 µF |
| Bus Overvoltage | 400 VDC |
| Internal Shunt Resistance | N/A |
| Continuous Power Output @ 115 VAC Input | 1.0 kW |
| Continuous Power Output @ 230 VAC Input | 2.0 kW |
| Recommended Input Wire Size | 3 mm² (12 AWG) |
| Recommended Class CC Fuse | FNQ-R-20 |
| Recommended Class J Fuse | LPJ-20SP |
| Maximum Power Loss | 50 W |
| Operating Temperature | 0°C to 55°C (32°F to 131°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Relative Humidity | 5–95%, Non-Condensing |
| Altitude | 1500 m; derate 3% per 300 m above 1500 m |
| Vibration | 5–2000 Hz @ 2.5 g Peak |
| Shock | 15 g, 11 ms Half-Sine |
| Compatible AC Line Filter | 2090-UXLF-123 |
| Primary Function | Servo drive for controlling compatible servo motors in motion-control applications |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The Allen-Bradley 2098-DSD-020-SE is an Ultra3000 Digital Servo Drive designed for precise motion control and servo motor applications. Operating from a 100–240 VAC single-phase supply, it delivers up to 2.0 kW continuous output power at 230 VAC with 10 A continuous and 30 A intermittent output current. The Allen-Bradley 2098-DSD-020-SE provides responsive servo control for positioning, speed, and motion applications in packaging machinery, material handling, assembly equipment, manufacturing, and other industrial automation systems.
Q1: What is the Allen-Bradley 2098-DSD-020-SE Ultra3000 Digital Servo Drive?
The 2098-DSD-020-SE is an Ultra3000 digital servo drive designed to control compatible servo motors in industrial positioning, speed-control, and motion applications.
Q2: How much continuous power can the Ultra3000 2098-DSD-020-SE deliver?
It provides up to 1.0 kW continuous output with a 115 VAC input and up to 2.0 kW with a 230 VAC input.
Q3: What output current is available from the 2098-DSD-020-SE?
The 2098-DSD-020-SE provides 10 A continuous output current and up to 30 A intermittent output current for dynamic servo applications.
Q4: What types of motion applications can use this Ultra3000 servo drive?
It is suitable for positioning, indexing, speed control, assembly, packaging, material handling, and other automated machinery requiring precise servo motion.
Q5: What AC line filter is compatible with the 2098-DSD-020-SE?
The 2098-DSD-020-SE lists the Allen-Bradley 2090-UXLF-123 as a compatible AC line filter.
Q6: Why use the Allen-Bradley 2098-DSD-020-SE for an existing motion-control system?
The 2098-DSD-020-SE provides a practical servo drive solution for maintaining, repairing, or supporting existing Ultra3000-based machinery while preserving compatibility with established motion-control architectures.
