Product Name: Stratix 5700 Ethernet Managed Switches
Brand Name: Allen Bradley
Model Number:1783-BMS20CL
Country of Origin:USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Allen Bradley |
Model Number: |
1783-BMS20CL |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
Delivery time in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Parameter |
Specification |
|
Manufacturer |
Rockwell Automation / Allen-Bradley |
|
Catalog Number |
1783-BMS20CL |
|
Product Type |
Stratix 5700 Managed Industrial Ethernet Switch |
|
Total Ports |
20 |
|
Copper Ports |
|
|
Combo Ports |
|
|
SFP Ports |
|
|
Firmware Version |
|
|
Management |
|
|
Mounting |
|
|
Input Voltage |
|
|
Power Consumption |
|
|
Max Power |
|
|
Current Draw |
0.5–3.0 A |
|
Dimensions (W × H × D) |
|
|
Weight |
|
|
Operating Temperature |
|
|
Storage Temperature |
-40°C to +70°C |
|
Ingress Protection |
|
|
DLR Support |
|
|
CIP Sync |
|
|
IEEE 1588 (PTP) |
No |
|
NAT Support |
No |
|
Lifecycle Status |
|
|
Replacement Product |
1783-CMS20DB |
The 1783-BMS20CL is a Stratix 5700 managed industrial Ethernet switch from Allen‑Bradley, offering 20 ports of reliable network connectivity for demanding automation environments. This 1783‑BMS20CL switch provides 16 Fast Ethernet copper ports, 2 combo ports, and 2 SFP slots, all configurable via Lite firmware. The 1783‑BMS20CL supports Device Level Ring (DLR) for network resilience and CIP Sync for time synchronization. Engineered for extreme conditions, the 1783‑BMS20CL operates from -40°C to +60°C and mounts on DIN rail for convenient installation.
Industrial automation and control networks
Factory floor and process automation
Machine builder and OEM applications
Extreme temperature environments (-40°C to +60°C)
Distributed control systems requiring DLR redundancy
Integration with Rockwell Automation Integrated Architecture
Operating Temperature:-40°C to +60°C (-40°F to +140°F)
Storage Temperature:-40°C to +70°C
Ingress Protection:IP30 (dust-resistant)
Humidity:Designed for industrial environments
Mounting:DIN rail (top hat 35mm)
Conformal:Coating Not specified for this model (standard version)
The 1783-BMS20CL functions as a Layer 2 managed switch, providing secure and reliable network connectivity for industrial control systems. It supports Device Level Ring (DLR) for ring-based network redundancy, ensuring automatic failover in case of cable breaks. The switch integrates with Rockwell Automation's Integrated Architecture via Add-On Profiles and provides FactoryTalk View faceplates for status monitoring and alarming. Predefined Logix tags deliver premium diagnostics for better network analysis. The switch also supports dual power inputs for enhanced power reliability.
Q1: What is the primary function of the 1783-BMS20CL?
A1: The 1783-BMS20CL is a 20-port managed industrial Ethernet switch that provides reliable network connectivity for Rockwell Automation control systems.
Q2: What are the port configurations of the 1783-BMS20CL?
A2: It has 16 x 10/100 Mbps copper ports, 2 x combo ports (copper or SFP), and 2 x SFP slots.
Q3: What is the operating temperature range of the 1783-BMS20CL?
A3: The switch operates from -40°C to +60°C (-40°F to +140°F).
Q4: Is the 1783-BMS20CL still available for purchase?
A4: No, the 1783-BMS20CL was discontinued on September 1, 2024. The recommended replacement is 1783-CMS20DB.
Q5: Does the 1783-BMS20CL support DLR?
A5: Yes, the 1783-BMS20CL supports Device Level Ring (DLR) for network redundancy.
