Product Name:High-Precision Industrial Measurement Sensor
Brand Name:Bently Nevada
Model Number:10030-05-30-05-02
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
10030-05-30-05-02 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Description |
|
Product Model |
10030-05-30-05-02 |
|
Series |
7200 Series Compatible Proximity Probe |
|
Probe Type |
Eddy current proximity transducer |
|
Tip Material |
Ryton |
|
Case Material |
Stainless Steel (Series 300 SS) |
|
Cable Type |
Coaxial cable with Tefzel insulation |
|
Impedance |
95 Ω |
|
Operating Temperature |
-40°C to +177°C |
|
Humidity Rating |
100% condensing (non-submersible) |
|
Pressure Design |
Standard sealed probe construction |
|
Connector Type |
Gold-plated brass hex connector |
|
Minimum Bend Radius |
1 inch (without armor) |
|
Weight |
0.04kg |
|
System Length |
5 m or 9 m (probe + cable combined) |
|
Dimension |
55.5x1.5x1.5cm |
10030-05-30-05-02 is a precision proximity probe assembly designed for legacy 7200 Series 5 mm & 8 mm vibration monitoring systems, widely used in rotating machinery condition monitoring applications. It is engineered to maintain full compatibility with existing probe, extension cable, and driver configurations, ensuring stable signal transmission in retrofit and replacement scenarios.
The 10030-05-30-05-02 supports accurate shaft vibration and displacement measurement, following API 670 compliance requirements and ProxMatch™ coding standards for correct system pairing. It is suitable for industrial installations where long-term monitoring reliability is required without modifying existing infrastructure.
Built for harsh operating environments, the 10030-05-30-05-02 provides durable performance in turbines, compressors, and heavy industrial machinery, extending the lifecycle of installed 7200 Series monitoring systems.
Q1: Is 10030-05-30-05-02 compatible with 7200 Series systems?
A1: Yes, it is designed specifically for 7200 Series 5 mm and 8 mm probe systems.
Q2: Can it be used for retrofit applications?
A2: Yes, it is commonly used to replace aging probes in existing installations.
Q3: What standard does this probe follow?
A3: It complies with API 670 vibration monitoring standards.
Q4: What is the operating temperature range?
A4: The probe operates from -40°C to +177°C in industrial environments.
Q5: Does it support harsh industrial conditions?
A5: Yes, it is designed for high vibration, high temperature, and EMI-heavy environments.
