Bently Nevada 140734-02 3500/42M Proximitor Seismic Monitor Ready For Ship, China Bently Nevada 140734-02 3500/42M Proximitor Seismic Monitor Ready For Ship Manufacturers, Suppliers, Factory

Overview

Brand Name:	Bently Nevada
Model Number:	3500/42M 140734-02
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Specification
Model	3500/42M 140734-02
Series	Bently Nevada 3500 Series
Channels	4-channel monitor
Input Types	Proximity, velocity, acceleration
Power Consumption	7.7 W typical
Operating Temperature	-30°C to +65°C
Storage Temperature	-40°C to +85°C
Input Impedance	10 kΩ
Output Type	4–20 mA, buffered output
Dimensions	2.5x25.5x24cm
Weight	0.82kg

Description

The3500/42M 140734-02is a high-performance Proximitor Seismic Monitor from theBently Nevada 3500 series, designed for continuous protection and condition monitoring of rotating machinery. It processes inputs from proximity, velocity, and acceleration sensors to deliver accurate vibration, displacement, and shaft position data for critical industrial assets.

The3500/42Mprovides multi-channel signal conditioning and compares real-time machine parameters against user-defined alarm thresholds. It supports multiple measurement types such as radial vibration, thrust position, differential expansion, and velocity, ensuring flexible monitoring across complex turbine and industrial systems.

Engineered for reliability, the3500/42M 140734-02integrates advanced filtering, buffered outputs, and diagnostic LEDs for system status indication. It is widely used in high-demand environments requiring precise vibration analysis, predictive maintenance, and machinery protection.

Applications

Power plants: Used for generator set status monitoring and relay protection.
Substations: Enable bus differential control, line protection, and switchyard signal acquisition.
Chemical plants: Integrate process control automation and intrinsically safe signal monitoring.
Steel mills (metallurgical plants): Perform equipment logic control in harsh environments with high temperatures and strong electromagnetic interference.
Machinery manufacturing plants: Used for automated production lines, robotic workstations, and packaging equipment control.

Features

4-channel multi-signal monitoring capability
Supports proximity, velocity, and acceleration inputs
Advanced signal conditioning and filtering system
LED status indicators for quick diagnostics
Buffered outputs with short-circuit protection
High EMC immunity for industrial environments
Fully programmable alarm and shutdown logic

Functions

Real-time vibration and displacement monitoring
Shaft position and thrust measurement
Machinery protection via alarm setpoints
Signal conditioning for predictive maintenance
Multi-parameter machine health analysis

FAQ

Q1: What is the main function of the 3500/42M 140734-02?
A1: It monitors vibration, displacement, and shaft position for industrial machinery protection.

Q2: How many channels does the 3500/42M support?
A2: It supports up to four independent monitoring channels.

Q3: What types of sensors are compatible?
A3: It accepts proximity, velocity, and acceleration transducer inputs.

Q4: Is the system suitable for harsh environments?
A4: Yes, it is designed for high EMI and industrial operating conditions.

Q5: Can alarm settings be customized?
A5: Yes, all channels support programmable alarm and danger setpoints.

Spares

Number	Describe
176449-02	3500/42M Proximitor Seismic Monitor
128229-01	Prox/Seismic I/O Module with internal terminations
128240-01	Prox/Seismic I/O Module with external terminations
00530843	3500/42M Prox/Seismic I/O Module four-pin connector shunt
143489	3500/42M Monitor User Guide
135489-01	I/O Module with Internal Barriers (internal terminations, 4 x Prox/Accel)
135489-02	I/O Module with Internal Barriers (internal terminations, 2 x Prox/Accel and 2 x Velomitor)
135489-03	I/O Module with Internal Barriers (internal terminations, 4 x Velomitor)
138708-01	Shaft Absolute I/O Module with internal terminations
138700-01	Shaft Absolute I/O Modules with external terminations
00517018	3500/42M Shaft Absolute I/O Module 8-pin connector shunt
