Product Name: Interconnect Cable
Brand Name: Bently Nevada
Model Number: 16925-12
Place of Origin: United States
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
overview
| Product Name | Interconnect Cable |
| Brand Name | Bently Nevada |
| Model Number | 16925-12 |
| Place of Origin | USA |
| Warranty | 12 months |
| Payment Methods | T/T |
| Shipment | DHL/UPS/EMS/Fedex... |
|
Sales |
|
|
|
Jim Pei |
The Bently Nevada 16925-12 Interconnect Cable is an industrial-grade connection cable designed for reliable signal transmission between monitoring devices and control systems. It features a shielded multi-conductor construction with 3 twisted pairs (6 conductors) and a conductor size of 22 AWG (0.5 mm²), ensuring stable electrical performance and strong resistance to electromagnetic interference. The cable is terminated with a 3-socket plug on one end and terminal lugs on the other, making it suitable for both plug-in connections and fixed wiring in control cabinets or equipment enclosures.
| Product Name | Bently Nevada 16925-12 Interconnect Cable |
| Manufacturer | Bently Nevada |
| Product Type | Interconnect Cable |
| Part Number | 16925-12 |
| Dimensions | 26x24x3cm |
| Weight | 0.15kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Conductors | 3 twisted pairs (6 conductors) |
| Wire Gauge | 24 AWG stranded copper |
| Shielding | Dual-layer,Individual foil per pair,Overall tinned copper braid (95% coverage) |
| Impedance | 100 Ω ±10% (1 kHz) |
| Capacitance | ≤30 pF/ft (pair-to-pair) |
| Max Voltage | 300 V AC/DC (continuous) |
| Resistance | ≤25 Ω/1000 ft (per conductor) |
| Connection at One End | 3-socket plug |
| Connection at the Other End | Terminal lugs |
| Minimum Length | 2.0 ft (0.6 m) |
| Maximum Length | 99 ft (30 m) |
22 AWG (0.5 mm²) stranded copper conductors for stable signal transmission
3 twisted pairs (6 conductors) for multi-signal communication
Dual-layer shielding with individual foil per pair and 95% tinned copper braid coverage
Impedance 100 Ω ±10% (at 1 kHz) for signal consistency
Low capacitance: ≤30 pF/ft (pair-to-pair) for reduced signal distortion
Maximum voltage rating(300 V AC/DC) continuous operation
Low resistance≤25 Ω/1000 ft per conductor
Flexible installation length range from 0.6 m (2 ft) to 30 m (99 ft)
3-socket plug for quick connection and terminal lugs for fixed wiring
Designed for industrial environments requiring reliable and stable cabling
The Bently Nevada 16925-12 Interconnect Cable is designed for use in industrial environments where stable signal transmission and strong noise immunity are required. Its shielded construction ensures reliable operation in electrically noisy areas such as control rooms, machinery enclosures, and industrial plants. It is suitable for fixed wiring in control cabinets as well as flexible routing in equipment installations, supporting continuous operation in power generation, oil & gas, and heavy industrial applications.
