Product Name:high-performance monitoring module
Brand Name:Bently Nevada
Model Number:3300/50
Country of Origin:USA
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
3300/50 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Product Type | Tachometer module for rotational speed monitoring, designed for industrial machinery protection systems |
| Model | 3300/50 Tachometer, supports multiple configuration options for speed, zero-speed, and acceleration monitoring |
| Input Channels | Single channel design, accepts dual transducer inputs with internal signal voting logic |
| Output Signal | Provides proportional voltage or current output for external data logging and monitoring systems |
| Relay Output | Configurable alert relay contacts for external annunciation and alarm signaling integration |
| Power Supply | Powered via rack system backplane, ensuring stable industrial-grade operation and compatibility |
| Operating Temperature | Designed for continuous operation in harsh industrial environments with stable performance |
| Dimensions | Standard rack-mounted module format, compact design optimized for 3300 series chassis integration |
| Weight | Approximately 0.5–0.8 kg, depending on configuration and relay option selection |
| Mounting Type | Rack-mounted installation within Bently Nevada 3300 system enclosure |
| Compliance | Supports CSA/NRTL/C and ATEX certified configurations for regulated industrial applications |
The 3300/50 Tachometer is a high-performance monitoring module designed for continuous measurement of shaft rotational speed, acceleration, and zero-speed detection in industrial machinery. It delivers stable and proportional voltage or current outputs, making it suitable for reliable signal transmission to external monitoring or recording systems.
This tachometer accepts dual transducer inputs within a single-channel architecture. Its built-in internal voting logic compares signals from both sensors, significantly reducing false readings caused by individual transducer faults and improving measurement reliability in critical rotating equipment.
Although it provides alert relay outputs for status indication, the device is intended strictly for monitoring and annunciation purposes. It is not designed as a safety-rated overspeed protection system. For protection applications, dedicated overspeed modules such as 3300/53 or 3500/53 are recommended for enhanced system safety.
Power plants: Used for generator speed monitoring, turbine rotation control, and alarm signal output in critical energy systems.
Substations: Enables rotational equipment supervision and signal acquisition for electrical distribution monitoring.
Chemical plants: Supports process equipment speed tracking and safe operation monitoring in hazardous environments.
Steel mills: Provides stable performance under high temperature, vibration, and electromagnetic interference conditions.
Machinery manufacturing plants: Applied in automated production lines, robotics systems, and packaging machinery control.
Q1: What is the main function of the 3300/50 Tachometer?
A1: It continuously monitors shaft speed, acceleration, and zero-speed conditions in rotating machinery.
Q2: Does the 3300/50 support multiple sensors?
A2: Yes, it accepts inputs from two transducers with internal voting logic for improved reliability.
Q3: Can it be used for overspeed protection?
A3: No, it is designed for monitoring and alarm purposes only, not as a safety-rated protection system.
Q4: What output signals does it provide?
A4: It provides proportional voltage or current outputs along with relay-based alert signals.
Q5: Where is the 3300/50 typically used?
A5: It is widely used in power plants, steel mills, chemical facilities, and industrial machinery systems.
|
Number |
Description |
|
148722-01 |
3300 XL Test Plug with three color-coded 1-meter leads and banana plugs for testing Proximitor Sensor performance without disconnecting field wiring. |
|
04310310 |
3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread-forming type. Four screws required per sensor installation. |
|
03200006 |
Silicone self-fusing tape, 9.1 m (10 yd) roll, providing electrical insulation and environmental protection for connectors. |
|
40113-02 |
Connector Protector Kit for 3300 XL 8 mm probes and extension cables, including connector protectors and installation tools. |
|
136536-01 |
Connector protector adapter for compatibility with pre-1998 installation tools used with 75Ω ClickLoc connectors. |
|
40180-02 |
Package containing 10 pairs of connector protectors for 3300 XL 8 mm probes and extension cables. |
|
03839410 |
75Ω triaxial male connector protector for extension cable connections, providing environmental protection against moisture and contaminants. |
|
03839420 |
75Ω triaxial female connector protector for probe and extension cable connections, providing environmental sealing and connector protection. |
|
04301007 |
3/8-24 probe lock nut with dual safety-wire holes for secure probe mounting in vibration-prone applications. |
|
04301008 |
M10 × 1 probe lock nut with dual safety-wire holes for secure installation and retention of proximity probes. |
|
330153-01 |
3300 XL Connector Kit containing male and female ClickLoc connectors, color-coded sleeves, FEP tubing, and silicone tape for cable termination and maintenance. |
