Product Name:3300 XL 8 mm Proximity Probes
Brand Name:Bently Nevada
Model Number:330101-00-19-10-02-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330101-00-19-10-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Specification |
|
Model |
330101-00-19-10-02-00 |
|
System Type |
3300 XL 8 mm Proximity Transducer System |
|
Probe Diameter |
8 mm |
|
Output Sensitivity |
7.87 V/mm (200 mV/mil) |
|
Linear Range |
2 mm (approx.) |
|
Operating Temperature |
-52°C to +177°C |
|
Cable Type |
75Ω triaxial shielded cable |
|
Connector Type |
ClickLoc gold-plated connector |
|
Power Supply |
-17.5 Vdc to -26 Vdc |
|
Mounting Style |
Threaded / panel compatible |
|
Weight |
0.06kg |
|
Dimension |
122x1.5x1.2cm |
The 330101-00-19-10-02-00 is part of the advanced Bently Nevada 3300 XL 8 mm Proximity Transducer System, designed for precise vibration and position monitoring in rotating machinery. It includes an 8 mm proximity probe, extension cable, and Proximitor sensor, delivering stable eddy-current measurement output proportional to shaft displacement for both static and dynamic conditions.
Engineered for high reliability, the 330101-00-19-10-02-00 supports industrial-grade monitoring in turbine, compressor, and fluid-film bearing systems. Its ClickLoc connector design ensures secure, tool-free installation with strong resistance to vibration loosening and environmental contamination.
With API 670-compliant performance and strong EMI/RFI immunity, the system ensures accurate signal integrity even in harsh electrical environments. It is widely used in critical asset protection systems where continuous condition monitoring and machine safety are required.
Q1: What is the 330101-00-19-10-02-00 used for?
A1: It is used for measuring shaft vibration and position in rotating machinery such as turbines and compressors.
Q2: Is the 330101 compatible with other 3300 XL components?
A2: Yes, it is fully compatible with the Bently Nevada 3300 XL 8 mm system including probes, cables, and sensors.
Q3: What industries use this proximity transducer system?
A3: It is widely used in power plants, petrochemical facilities, steel mills, and industrial automation systems.
Q4: Can it operate in high-temperature environments?
A4: Yes, the system supports extended operating temperatures up to 177°C depending on configuration.
Q5: Does it support EMI-resistant performance?
A5: Yes, the system features strong EMI/RFI immunity for stable operation in electrically noisy environments.
| Number (I/O Module / Item) | Describe |
|---|---|
| 148722-01 | 3300 XL Test Plug used to verify Proximitor sensor performance via test pin access without removing field wiring. Includes 3 color-coded 1 m leads with banana plugs. |
| 330187 | Extended Range Micrometer Kit for acceptance testing of Bently Nevada extended range transducers, includes precision micrometer and AISI 4140 target. |
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire, sold by length. |
| 02173009 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor twisted shielded cable, sold by length for industrial signal wiring. |
| 138492-01 | Replacement panel-mount mounting pad for 3300 XL installation systems. |
| 138493-01 | Replacement DIN-mount mounting pad for modular 3300 XL sensor mounting configurations. |
| 04310310 | Panel-mount screw kit including four 6-32 UNC thread forming screws for Proximitor sensor housing installation. |
| 03200006 | Silicone self-fusing tape (9.1 m roll) for connector protection and environmental sealing, not recommended for internal machine use. |
| 40113-02 | Connector Protector Kit for 3300 XL probes and extension cables, includes protectors and installation tools. |
| 29660-01 | Transducer clamp designed for 1.06” smooth 3300 XL 25 mm probe cases (-03 and -04 variants only). |
| 136536-01 | Connector protector adapter allowing legacy connector kits to be used with 3300 XL ClickLoc connectors. |
| 40180-02 | Connector protector set including 10 pairs of protective connector covers for probes and extension cables. |
| 03839410 | Male connector protector for extension cable side, ensures environmental sealing when connected to probe. |
| 03839420 | Female connector protector for probe lead or Proximitor connection protection against contamination and moisture. |
| 330153-08 | 3300 XL 25 mm connector kit including male/female ClickLoc connectors, sleeves, and slit PFA tubing. |
| 163356 | Connector crimp tool kit with multi-connector inserts and installation instructions for ClickLoc connector assembly. |
