Product Name:Full-height Monitor Blank Front Panel
Brand Name:Bently Nevada
Model Number:128275-01F 130944-01
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
128275-01F 130944-01 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Description |
|---|---|
| Product Model | 128275-01F / 130944-01 |
| System Type | 3500 Rack System |
| Rack Size | Full-size (14 slots) / Mini-rack (7 slots) |
| Mounting Type | Panel / Rack / Bulkhead |
| Power Distribution | Backplane integrated |
| Communication | Internal rack backplane bus |
| Material | Industrial-grade metal chassis |
| Dimension (Full Rack) | 482 × 266 × 305 mm |
| Dimension (Mini Rack) | 305 × 266 × 305 mm |
| Weight (Full Rack) | ~6.5 kg |
| Weight (Mini Rack) | ~4.2 kg |
| Operating Temp | -30°C to +65°C |
The128275-01Fand130944-01rack system components are designed for integration within Bently Nevada 3500 monitoring architectures, providing a structured platform for industrial protection and condition monitoring modules. These rack assemblies ensure stable housing and reliable backplane communication between system modules.
The3500 rack platformsupports multiple configurations, including full-size and mini-rack formats, allowing flexible installation in control panels, EIA rack systems, or bulkhead-mounted environments. It enables seamless power distribution and high-speed data communication across all installed monitoring modules and power supplies.
Engineered for industrial reliability,128275-01F / 130944-01systems are widely used in critical process industries. They support hazardous area compliance options and are suitable for applications requiring continuous monitoring, high system integrity, and robust mechanical installation in demanding environments.
Q1: What is the main function of 128275-01F / 130944-01 rack system?
A1: It provides housing, power distribution, and communication support for Bently Nevada 3500 monitoring modules.
Q2: How many modules can the rack support?
A2: The full-size rack supports up to 14 modules, while the mini-rack supports 7 modules.
Q3: What mounting options are available?
A3: It supports panel mount, rack mount, and bulkhead mount configurations depending on installation needs.
Q4: Is the rack suitable for hazardous environments?
A4: Yes, it supports configurations with hazardous area approvals depending on system setup.
Q5: Can it be used with other 3500 system modules?
A5: Yes, it is fully compatible with Bently Nevada 3500 series monitoring and power modules.
| number | describe |
|---|---|
| 125388-01 | Half-height Module Internal Chassis (Qty 1) |
| 125565-01 | Half-height Module Card Guide (Qty 1) |
| 04300111 | Screws for Half-height Module Internal Chassis (Qty 3) |
| 131150-01 | Power Supply Blank Front Panel (Qty 1) |
| 128085-01 | Power Supply Input Connector Cover (Qty 1) |
| 04310251 | Screw for Power Supply Input Cover (Qty 2) |
| 130944-01 | Full-height Monitor Blank Front Panel (Qty 1) |
| 128031-01 | I/O Module Cover (Qty 1) |
| 131151-01 | Half-height Blank Front Panel Cover (Qty 1) |
| 00517016 | TMR/SIM jumper (installed on 3500 backplane) |
| 144863-01 | Adapter Panel, Mini-rack, 19-inch |
| 129766-01 | Rack Installation and Maintenance Manual |
| 130432-01 | Field Wiring Diagrams |
