Product Name: 3300 XL 8 mm Proximity Probes
Brand Name: BENTLY NEVADA
Model Number: 330104-00-20-10-01-CN
Country of Origin:USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
overview
| Product Name | 3300 XL 8 mm Proximity Probes |
| Brand Name | Bently Nevada |
| Model Number | 330104-00-20-10-01-CN |
| Place of Origin | USA |
| Warranty | 12 months |
| Payment Methods | T/T |
| Shipment | DHL/UPS/EMS/Fedex... |
The BENTLY NEVADA 330104-00-20-10-01-CN 3300 XL 8mm Proximity Probe is a rugged, high-performance non-contact sensor designed for precise measurement of vibration and shaft position in industrial machinery. Developed by Bently Nevada, this probe is part of the trusted 3300 XL series widely used in machinery protection and condition monitoring systems. It features a durable PPS (polyphenylene sulfide) tip, AISI 303/304 stainless steel body, and Viton® O-ring seal to ensure reliable operation under pressure and in harsh environments. Manufactured is built for long-term stability and accuracy in demanding industrial applications.
Non-contact vibration measurement
Accurately monitors shaft vibration without physical contact, reducing wear and improving measurement reliability.
Shaft position and displacement detection
Provides precise measurement of shaft movement for real-time machinery condition assessment.
Continuous condition monitoring
Supports early fault detection in rotating equipment such as turbines, compressors, and motors.
Stable signal output
Delivers consistent electrical signals with high sensitivity, enabling integration with monitoring and control systems.
System integration capability
Works seamlessly within the 3300 XL proximity transducer system, ensuring accurate and standardized monitoring results.
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
| Product Name | BENTLY NEVADA 330104-00-20-10-01-CN 3300 XL 8mm Proximity Probe |
| Manufacturer | BENTLY NEVADA |
| Product Type | 3300 XL 8mm Proximity Probe |
| Part Number | 330104-00-20-10-01-CN |
| Dimensions | 1.8x1.6x123cm |
| Weight | 0.2kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Condition | New & Original in Factory Packing |
| Power | Needs -17.5Vdc to -26Vdc (max 12mA) |
| Sensitivity | Output changes less than 2mV per 1V input shift |
| Output resistance | 50 Ω |
| Probe resistance | 7.59Ω ±0.5Ω (1.0m length). |
| Power With barriers | -23Vdc to -26Vdc |
| Best temp | 18°C to 27°C (64°F to 80°F) |
| Max height | 2000 meters |
| Calibrate | Use AISI 4140 steel targets for best accuracy |
| Tip | Made of PPS (polyphenylene sulfide) |
| Body | AISI 303/304 stainless steel |
| Seal | Viton® O-ring to handle pressure |
| Unthreaded length | 0mm |
| Body length | 200mm |
| Total length | 1.0m / 3.3ft |
The BENTLY NEVADA 330104-00-20-10-01-CN 3300 XL 8mm Proximity Probe is designed for demanding industrial environments, combining durability, precision, and reliability.
It uses non-contact eddy current technology to accurately measure vibration and shaft position without mechanical wear.
Features a high-strength PPS (polyphenylene sulfide) tip, providing excellent thermal stability and chemical resistance.
Built with an AISI 303/304 stainless steel body for superior corrosion resistance and mechanical strength.
Equipped with a Viton® O-ring seal to ensure effective pressure sealing and environmental protection.
Provides stable electrical performance with a consistent output resistance of 50 Ω.
Offers high sensitivity, with less than 2 mV change per volt input shift for precise measurements.
Operates within an optimal temperature range of 18°C to 27°C for accurate performance.
Suitable for installations up to 2000 meters in elevation.
Compact yet robust design with a mini coaxial ClickLoc connector for secure installation and long-term reliability.
Q1: What is the main application of BENTLY NEVADA 330104-00-20-10-01-CN 3300 XL 8mm Proximity Probe?
A: The BENTLY NEVADA 330104-00-20-10-01-CN Proximity Probe is primarily used for non-contact vibration and shaft position monitoring, ensures accurate condition monitoring in critical rotating machinery, making the 330104-00-20-10-01-CN essential for industrial protection systems.
Q2: What materials are used in BENTLY NEVADA 330104-00-20-10-01-CN Proximity Probe?
A: The 330104-00-20-10-01-CN is constructed with a PPS tip, stainless steel (AISI 303/304) body, and Viton® O-ring seal.
Q3: How does BENTLY NEVADA 330104-00-20-10-01-CN 3300 XL Proximity Probe ensure measurement accuracy?
A: The Probe uses eddy current technology and is calibrated with AISI 4140 steel targets, and the 330104-00-20-10-01-CN Proximity Probe provides high sensitivity for precise readings, making the probe suitable for critical monitoring tasks.
Q4: What connector type is used in BENTLY NEVADA 330104-00-20-10-01-CN 3300 XL 8mm Proximity Probe?
A: The Probe uses a mini coaxial ClickLoc connector, ensures secure and stable connections, making the BENTLY NEVADA 330104-00-20-10-01-CN 3300 XL 8mm Proximity Probe easy to install and maintain.
The BENTLY NEVADA 330104-00-20-10-01-CN is fully compatible with the 3300 XL 8mm proximity transducer system, where it operates as part of an integrated setup including the probe, extension cable, and Proximitor sensor. These components are factory-matched to ensure accurate signal transmission and eliminate the need for additional calibration during installation. The probe is interchangeable with other 3300 XL 8mm system components, allowing flexible maintenance and replacement without affecting system performance. It also maintains backward compatibility with earlier 3300 series systems, supporting system upgrades without complete redesign. In terms of interoperability, the probe integrates seamlessly with industrial monitoring and control platforms such as PLC and DCS systems, using standardized signal outputs for vibration and position monitoring. Its design aligns with industry practices (including API 670-based systems), making it suitable for use in turbines, compressors, motors, and other critical rotating machinery where reliable condition monitoring is essential.
