Product Name:3300 XL 8 mm Proximity Probes
Brand Name:Bently Nevada
Model Number:330101-04-28-10-02-00
Country of Origin:USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330101-04-28-10-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Specification |
|---|---|
| Model | 330101-04-28-10-02-00 |
| Series | Bently Nevada 3300 XL 8 mm Probe |
| Thread Type | 3/8-24 UNF |
| Total Length | 1.0 m (configurable system dependent) |
| Case Length | 2.8 in (configurable range) |
| Unthreaded Length | 0.4 in |
| Cable Type | FluidLoc / Standard coaxial cable |
| Connector Type | Miniature ClickLoc connector |
| Operating Temperature | -52°C to +177°C |
| Linear Range | Approx. 2 mm |
| Material | Stainless steel (AISI 304/303) |
| Dimensions | 1.99 in body diameter (approx.) |
| Weight | ~0.7 kg system typical |
The 330101-04-28-10-02-00 3300 XL 8 mm Proximity Probe is a high-precision eddy current sensor designed for reliable vibration and shaft position monitoring in industrial rotating equipment. Built within the Bently Nevada 3300 XL 8 mm series, it delivers accurate non-contact measurement of both static and dynamic movement, ensuring stable performance in critical machinery applications.
The 330101-04-28-10-02-00 probe features a robust threaded design and optional armored construction, providing excellent mechanical durability and resistance to harsh operating conditions. Its ClickLoc connector system and FluidLoc cable technology enhance installation reliability while preventing contamination and fluid ingress.
Engineered for compatibility with the full 3300 XL monitoring system, the 330101-04-28-10-02-00 supports turbine, compressor, and pump condition monitoring, offering long-term stability, interchangeability, and compliance with API 670 performance standards.
Q1: What is the main use of the 330101-04-28-10-02-00 probe?
A1: It is used for measuring shaft vibration and position in turbines, compressors, and rotating industrial equipment.
Q2: Is the 3300 XL 8 mm probe compatible with older systems?
A2: Yes, it is backward compatible with non-XL 3300 5 mm and 8 mm systems.
Q3: Can this probe operate in high-temperature environments?
A3: Yes, it supports continuous operation up to 177°C and harsh industrial conditions.
Q4: What is the benefit of FluidLoc cable technology?
A4: It prevents oil and fluid ingress, improving long-term reliability and sensor protection.
Q5: Does the probe support armored cable options?
A5: Yes, armored configurations are available for enhanced mechanical protection in demanding environments.
| Number | Description |
|---|---|
| 141078 | 3300 XL 8 mm and 3300 5 mm Proximity Transducer System manual for installation, configuration, and maintenance guidance. |
| 175751 | 3300 XL multi-purpose stainless steel housing (12”×12”×6”), supports up to 8 DIN-mount or 6 panel-mount Proximitor sensors, ATEX Zone 0/1 certified. |
| 176467 | 3300 XL stainless steel housing (12”×8”×6”), supports up to 4 Proximitor sensors in DIN or panel mounting configurations, ATEX certified option available. |
| 330181 | 3300 XL multi-purpose stainless steel enclosure (13”×9.5”×7”), supports up to 8 DIN-mount or 6 panel-mount sensors, suitable for hazardous area installations. |
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire, length specified in feet. |
| 138492-01 | Replacement panel-mount mounting pad for Proximitor sensor installation. |
| 138493-01 | Replacement DIN-mount mounting pad for standard DIN rail installation. |
| 148722-01 | 3300 XL test plug with 3-pin adapter and color-coded wires for Proximitor sensor performance testing without removing field wiring. |
| 04310310 | 3300 XL Proximitor sensor panel-mount screw kit, includes 6-32 UNC thread-forming screws (4 required per sensor). |
| 03200006 | Silicone self-fusing tape (9.1 m roll) for connector protection, providing insulation and environmental sealing. |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables, includes protectors and installation tools. |
| 136536-01 | Connector protector adapter allowing compatibility with pre-1998 installation tools for 75Ω ClickLoc connectors. |
| 40180-02 | Connector protectors kit containing 10 pairs of protective connectors for probes and extension cables. |
| 03839410 | 75Ω triaxial male connector protector for extension cable-side environmental sealing. |
| 03839420 | 75Ω triaxial female connector protector for probe lead and Proximitor sensor connection protection. |
