Product Name:3300 XL 8 mm Proximity Probes
Brand Name:Bently Nevada
Model Number:330101-30-63-15-02-CN
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330101-30-63-15-02-CN |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Description |
|
Model |
330101-30-63-15-02-CN |
|
System Type |
3300 XL 8 mm Proximity Probe |
|
Thread Type |
3/8-24 UNF |
|
Cable Type |
Coaxial triaxial cable |
|
Output |
Eddy current displacement signal |
|
Measurement Range |
0.25–2.3 mm linear range |
|
Operating Temp |
-52°C to +177°C |
|
Cable Length |
1.5–9.0 m options |
|
Weight |
0.12kg |
|
Dimension |
22x20x2cm |
|
Unthreaded Length Option |
3in |
|
Overall Case Length Option |
6.3in |
|
Total Length Option |
1.5 meter (4.9 feet) |
|
Connector and Cable-Type Option |
Miniature coaxial ClickLoc connector, standard cable |
The 330101-30-63-15-02-CN is a high-performance 3300 XL 8 mm proximity probe designed for precise vibration and position monitoring in industrial rotating equipment. As part of the 3300 XL 8 mm Proximity Transducer System, it delivers stable, non-contact measurement of shaft movement, ensuring reliable condition monitoring in demanding environments.
This probe works in combination with a 3300 XL extension cable and Proximitor sensor, forming a complete eddy current measurement chain. Models such as 330101 and other 3300 XL variants are engineered for compatibility, interchangeability, and long-term installation flexibility across different machine configurations.
With rugged construction and advanced signal stability, the 330101-30-63-15-02-CN supports critical applications such as turbines, compressors, and pumps. It is widely used in industries requiring accurate dynamic measurement, helping improve equipment reliability and predictive maintenance performance.
Power plants: Used for generator set vibration monitoring and protection systems.
Substations: Enable signal acquisition, relay protection, and switchyard control.
Chemical plants: Support intrinsically safe automation and process monitoring.
Steel mills: Operate reliably under high temperature and EMI environments.
Machinery plants: Applied in automation lines, robotics, and control systems.
Q1: What is the 330101-30-63-15-02-CN used for?
A1: It is used for non-contact vibration and position monitoring of rotating machinery in industrial systems.
Q2: Is the 330101 probe compatible with other 3300 XL systems?
A2: Yes, it is fully compatible with 3300 XL extension cables and Proximitor sensors.
Q3: Can it operate in high-temperature environments?
A3: Yes, it supports operation up to +177°C in standard configurations.
Q4: What industries commonly use this probe?
A4: It is widely used in power generation, petrochemical, steel, and manufacturing industries.
Q5: Does it require calibration before installation?
A5: No, it is factory calibrated and designed for direct installation with interchangeable components.
| Number | Description |
|---|---|
| 148722-01 | 3300 XL test plug with 3 color-coded test pins and 1-meter banana plug wires for Proximitor sensor performance testing without removing field wiring. |
| 04310310 | 3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread forming mounting screw, 4 screws required per sensor. |
| 03200006 | Silicone self-fusing tape, 9.1 m roll, used for connector insulation and environmental protection, not recommended for internal machine use. |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables, includes protectors and installation tools. |
| 136536-01 | Connector protector adapter enabling compatibility with pre-1998 installation tools for 75Ω ClickLoc connectors. |
| 40180-02 | Connector protectors kit, includes 10 pairs of protective covers for 3300 XL 8 mm probes and extension cables. |
| 03839410 | 75Ω triaxial male connector protector for extension cable, provides environmental protection for connector interface. |
| 03839420 | 75Ω triaxial female connector protector for probe lead or Proximitor sensor connection protection in harsh environments. |
| 04301007 | 3/8-24 probe lock nut with safety wire holes, designed for secure mechanical fixation of proximity probes. |
| 04301008 | M10 x 1 probe lock nut with safety wire holes for secure probe installation and anti-loosening protection. |
| 330153-01 | 3300 XL connector kit including male/female ClickLoc connectors, color-coded sleeves, FEP tubing, and silicone tape. |
