Product Name:3300 XL 8 mm Proximity Probes
Brand Name:BENTLY NEVADA
Model Number:330104-00-13-10-02-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330104-00-13-10-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Parameter |
Specification |
|
Model Number |
330104-00-13-10-02-00 |
|
Product Type |
3300 XL 8 mm Proximity Probe |
|
Thread Type |
M10 x 1 Metric Thread |
|
Armor Option |
Armored Cable |
|
Total Length |
1.0 meter (3.3 ft) |
|
Connector Type |
Miniature coaxial ClickLoc connector |
|
Probe Diameter |
8 mm |
|
Linear Range |
2 mm (80 mils) |
|
Frequency Response |
0 to 10 kHz |
|
Operating Temperature |
-52°C to +177°C |
|
Probe Tip Material |
Polyphenylene Sulfide (PPS) |
|
Housing Material |
AISI 303/304 Stainless Steel |
|
Cable Type |
75Ω Triaxial FEP Insulated Cable |
|
Recommended Gap Setting |
-9 Vdc at 1.27 mm |
|
Dimension |
2x112.5x1.8cm |
|
Weight |
0.16kg |
Bently Nevada 330104-00-13-10-02-00is a high-reliability proximity probe designed for continuous vibration and shaft position monitoring in rotating machinery. As part of the3300 XL 8 mm Proximity Transducer System, this model features an armored construction, M10 x 1 metric thread, and a durable stainless-steel housing suitable for demanding industrial environments. The integrated ClickLoc connector design improves installation stability while reducing maintenance time.
The330104-00-13-10-02-00probe delivers accurate non-contact measurement for turbines, compressors, pumps, and motors operating in power generation, petrochemical, and heavy manufacturing facilities. Its advanced eddy current sensing technology provides stable signal output for both dynamic vibration and static position monitoring applications.
Compatible with3300 XL Proximitor Sensors, extension cables, and selected non-XL 3300 series components, this probe supports flexible system integration. The rugged armored cable design enhances resistance to oil, moisture, vibration, and mechanical stress, making it ideal for long-term industrial condition monitoring systems.
Q1: What is the primary use of the 330104-00-13-10-02-00 probe?
A1: It is mainly used for vibration and shaft position monitoring in rotating industrial machinery.
Q2: Does the 330104-00-13-10-02-00 include armored protection?
A2: Yes, this model is equipped with an armored cable for improved mechanical durability.
Q3: Is this probe compatible with 3300 XL monitoring systems?
A3: Yes, it is fully compatible with Bently Nevada 3300 XL Proximitor sensors and extension cables.
Q4: What industries commonly use this proximity probe?
A4: Power generation, petrochemical, oil & gas, steel, and industrial manufacturing industries widely use this model.
Q5: What connector type does this probe use?
A5: The probe uses a miniature coaxial ClickLoc connector for fast and secure installation.
| Number | Description |
|---|---|
| 141078 | 3300 XL 8 mm and 3300 5 mm Proximity Transducer System manual |
| 175751 | 3300 XL stainless steel housing, 12”×12”×6”, supports up to 8 DIN-mount or 6 panel-mount Proximitor sensors |
| 176467 | 3300 XL stainless steel housing, 12”×8”×6”, supports up to 4 Proximitor sensors |
| 330181 | 3300 XL stainless steel housing, 13”×9.5”×7”, supports hazardous area certified installations |
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire |
| 138492-01 | Replacement panel-mount mounting pad |
| 138493-01 | Replacement DIN-mount mounting pad |
| 148722-01 | 3300 XL test plug with 3-pin adapter and banana plug leads for sensor testing |
| 04310310 | Panel-mount screw for 3300 XL Proximitor Sensor, 6-32 UNC thread |
| 03200006 | Silicone self-fusing tape for connector insulation and environmental protection |
| 40113-02 | Connector protector kit for 3300 XL probes and extension cables |
| 136536-01 | Connector protector adapter for pre-1998 installation tools and 75Ω ClickLoc connectors |
| 40180-02 | Package of 10 pairs of connector protectors for 3300 XL probes and extension cables |
| 03839410 | 75Ω triaxial male connector protector for extension cable environmental protection |
| 03839420 | 75Ω triaxial female connector protector for probe and Proximitor sensor connection protection |
| 04301007 | 3/8-24 probe lock nut with safety wire holes for secure installation |
