Honeywell FC-IO-0001 V1.1 IO Extender module In stock, China Honeywell FC-IO-0001 V1.1 IO Extender module In stock Manufacturers, Suppliers, Factory

Overview

Brand Name:	Honeywell
Model Number:	FC-IO-0001 V1.1
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Specification
Product Model	FC-IO-0001 V1.1
Function Type	IO Extender Module
System Compatibility	Safety Manager IO Systems
Power Supply	5 V DC
Current Consumption	35 mA
Ripple	< 50 mV p-p
Slot Width	4 TE
Height Unit	3 HE
Connector Type	DIN 41612 Type F
Operating Role	IO communication bridge
Installation	IO chassis mounted
Weight	0.12kg
Dimension	2x19x12.8cm

Description

TheFC-IO-0001 V1.1IO Extender Module is a core interface component designed for Safety Manager architectures, enabling stable data exchange between the Control Processor and field IO modules within industrial control systems. It is installed in the IO chassis and serves as the communication bridge for redundant and non-redundant configurations.

In redundant systems, such asIOCHAS-0001R, theFC-IO-0001 V1.1operates in dual-slot architecture (slot 20 and 21), ensuring continuous IO communication for high-availability applications. In non-redundant setups, a single module manages IO data transfer efficiently from slot 21. It can be replaced under powered conditions, although safety-related shutdown behavior may apply depending on system configuration.

Built for industrial reliability, theFC-IO-0001 V1.1supports robust chassis integration and ensures consistent IO bus performance in mission-critical automation environments.

Applications

Power plants: Used for generator set status monitoring and relay protection.
Substations: Enables bus differential control, line protection, and switchyard signal acquisition.
Chemical plants: Supports process automation and intrinsically safe signal monitoring.
Steel mills (metallurgical plants): Ensures stable IO communication under high temperature and EMI conditions.
Machinery manufacturing plants: Used in automated production lines, robotics, and packaging control systems.

Features

Designed for Safety Manager IO architecture integration
Supports redundant and non-redundant IO chassis systems
Stable communication between Control Processor and IO modules
Hot-replace capability under defined operating conditions
Compact DIN-based module design
Low power consumption with high reliability
Industrial-grade EMC resistance performance

Functions

Transfers IO communication between processor and field modules
Enables IO bus signal routing via chassis backplane
Supports chassis address configuration through jumper settings
Manages redundant IO channel synchronization
Ensures stable system-level IO data transmission
Maintains communication integrity in safety-critical control systems

FAQ

Q1: What is the FC-IO-0001 V1.1 used for?
A1: It is an IO extender module that connects the Control Processor with IO modules in Safety Manager systems.

Q2: Can FC-IO-0001 V1.1 work in redundant systems?
A2: Yes, it supports redundant IO chassis configurations for high-availability applications.

Q3: Where is the module installed?
A3: It is installed in the IO chassis, typically in slot 20 or 21 depending on system type.

Q4: Does it support hot swapping?
A4: Yes, it can be replaced while powered, but safety functions may trigger shutdown depending on configuration.

Q5: What power does FC-IO-0001 V1.1 require?
A5: It operates on a standard 5 V DC supply with low current consumption of about 35 mA.

Spares

number	describe
IO-0001	IO Extender Module (Safety Manager)
TERM-0001	Bus terminator for non-redundant IO
TERM-0002	Bus terminator for redundant IO
IO-0002	IO Extender Module (Safety Manager A.R.T.)
IOBUS-CPIO	IO Bus from Controller chassis to IO chassis
IOBUS-CPIOx	IO bus from Controller chassis to IO chassis
IOBUS-CPIOX	IO bus in extension cabinet
IOBUS-CPIOXx	IO bus in extension cabinet
IOBUS-CPX-x	IO bus from controller cabinet to extension cabinet
IOBUS-CPX1x	IO bus from controller cabinet to extension cabinet
