Product Name:3300 XL 8 mm Proximity Probes
Brand Name:Bently Nevada
Model Number:330102-10-40-10-02-00
Country of Origin:USA
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330102-10-40-10-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Specification |
|---|---|
| Model | 330102-10-40-10-02-00 |
| System Type | 3300 XL 8 mm Proximity Transducer System |
| Probe Thread | 3/8-24 UNF |
| Cable Type | Standard triaxial FEP insulated |
| System Length | 1.0 meter |
| Output Signal | Eddy current voltage proportional to gap |
| Measurement Range | 0.25 mm – 2.3 mm linear range |
| Frequency Response | 0 – 10 kHz |
| Probe Weight | ~323 g/m |
| Extension Cable Weight | ~34 g/m |
| Sensor Material | Aluminum housing |
| Operating Temperature | -52°C to +177°C |
| Storage Temperature | -52°C to +105°C |
The 330102-10-40-10-02-00 is part of the advanced 3300 XL 8 mm proximity transducer family designed for high-precision shaft vibration and position monitoring in rotating machinery. It integrates a rugged proximity probe, extension cable, and Proximitor sensor, forming a complete eddy-current measurement chain for industrial condition monitoring systems.
Built for reliable performance in demanding environments, the 3300 XL 8 mm system (including 330102 series probes) delivers stable voltage output proportional to the gap between the probe tip and conductive target surface. It supports both static displacement and dynamic vibration measurements, making it suitable for turbine, compressor, and motor protection applications.
Engineered with API 670 compliance and backward compatibility, the 330102-10-40-10-02-00 ensures seamless interchangeability with other 3300-series components. Its robust construction, improved EMI/RFI immunity, and high thermal stability make it ideal for continuous operation in harsh industrial environments where accuracy and long-term reliability are critical.
Q1: What is the 330102-10-40-10-02-00 used for?
A1: It is used for vibration and shaft position monitoring in rotating industrial machinery such as turbines, compressors, and generators.
Q2: Is the system compatible with other 3300 XL components?
A2: Yes, it is fully interchangeable with other 3300 XL 8 mm and selected legacy 3300 series components.
Q3: What measurements can it provide?
A3: It supports both static displacement and dynamic vibration measurements with high precision output.
Q4: Can it operate in high-temperature environments?
A4: Yes, it supports operation up to 177°C depending on system configuration and cable type.
Q5: Does it meet industrial standards?
A5: Yes, it is designed in compliance with API 670 for mechanical and performance reliability standards.
|
Number |
Description |
|
148722-01 |
3300 XL Test Plug with three color-coded 1-meter leads and banana plugs for testing Proximitor Sensor performance without disconnecting field wiring. |
|
04310310 |
3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread-forming type. Four screws required per sensor installation. |
|
03200006 |
Silicone self-fusing tape, 9.1 m (10 yd) roll, providing electrical insulation and environmental protection for connectors. |
|
40113-02 |
Connector Protector Kit for 3300 XL 8 mm probes and extension cables, including connector protectors and installation tools. |
|
136536-01 |
Connector protector adapter for compatibility with pre-1998 installation tools used with 75Ω ClickLoc connectors. |
|
40180-02 |
Package containing 10 pairs of connector protectors for 3300 XL 8 mm probes and extension cables. |
|
03839410 |
75Ω triaxial male connector protector for extension cable connections, providing environmental protection against moisture and contaminants. |
|
03839420 |
75Ω triaxial female connector protector for probe and extension cable connections, providing environmental sealing and connector protection. |
|
04301007 |
3/8-24 probe lock nut with dual safety-wire holes for secure probe mounting in vibration-prone applications. |
|
04301008 |
M10 × 1 probe lock nut with dual safety-wire holes for secure installation and retention of proximity probes. |
|
330153-01 |
3300 XL Connector Kit containing male and female ClickLoc connectors, color-coded sleeves, FEP tubing, and silicone tape for cable termination and maintenance. |
