Bently Nevada 136711-02 3500/61 RTD/TC I/O Module Original new, China Bently Nevada 136711-02 3500/61 RTD/TC I/O Module Original new Manufacturers, Suppliers, Factory

Overview

Brand Name:	Bently Nevada
Model Number:	136711-02
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Description
Product Model	3500/61 RTD/TC I/O Module (136711-02)
Channels	6 temperature input channels
Input Types	RTD / Thermocouple (TC)
Input Impedance	10 MΩ
Power Consumption	9 Watts nominal
Isolation	Channel-to-channel isolation (up to 250 Vdc for isolated version)
RTD Types	Pt100, Nickel, Copper RTDs supported
TC Types	E, J, K, T thermocouples
Accuracy	±1°C to ±3°C depending on configuration
Output Signal	4–20 mA per channel (recorder output)
Operating Temp	-30°C to +65°C
Storage Temp	-40°C to +85°C
Humidity	Up to 95% non-condensing
Dimensions	2.3x18.5x24.1cm
Weight	0.94kg

Description

The 3500/61 RTD/TC I/O Module (136711-02) is a high-performance temperature input interface designed for the Bently Nevada 3500 monitoring system. It supports up to six channels of RTD and thermocouple signals, enabling accurate multi-point temperature acquisition for industrial machinery protection and condition monitoring.

The 3500/61 processes and conditions temperature inputs in real time, comparing measured values against user-defined alarm thresholds. It is widely used in applications requiring stable thermal supervision, offering configurable RTD/TC compatibility and reliable signal integrity even in electrically noisy environments.

Unlike the 3500/60, the 3500/61 model provides individual recorder outputs for each channel, making it suitable for advanced diagnostics and system integration. It ensures precise monitoring performance in critical rotating and process equipment environments.

Applications

Power plants: Used for generator set status monitoring and relay protection.
Substations: Enable bus differential control, line protection, and switchyard signal acquisition.
Chemical plants: Integrate process control automation and intrinsically safe temperature monitoring.
Steel mills (metallurgical plants): Provide stable thermal monitoring under high temperature and EMI environments.
Machinery manufacturing plants: Used for automated production lines, robotic systems, and equipment thermal control.

Features

6-channel RTD and thermocouple input support
Compatible with multiple temperature sensor types
High-accuracy industrial temperature measurement
Channel isolation for improved signal integrity
Integrated alarm comparison with configurable setpoints
Built for harsh industrial environments
Recorder outputs available per channel (3500/61 only)

Functions

Multi-channel temperature data acquisition
Real-time thermal condition monitoring
Alarm triggering via programmable thresholds
Signal conditioning for RTD and TC inputs
Data output for control and monitoring systems
Industrial machinery protection and diagnostics
Integration with 3500 rack configuration software

FAQ

Q1: What is the 3500/61 used for?
A1: It is used for multi-channel temperature monitoring in industrial machinery and process systems.

Q2: How many input channels does the module support?
A2: The 3500/61 supports up to 6 RTD or thermocouple input channels.

Q3: What is the difference between 3500/60 and 3500/61?
A3: The 3500/61 includes recorder outputs for each channel, while the 3500/60 does not.

Q4: Which temperature sensors are compatible?
A4: It supports RTDs such as Pt100 and thermocouples including E, J, K, and T types.

Q5: Is the module suitable for harsh environments?
A5: Yes, it is designed for industrial conditions with high temperature and electrical noise resistance.

Spares

Number	Describe
133908-01	RTD/TC Non-Isolated External Termination Block (Terminal Strip connectors)
133916-01	RTD/TC Non-Isolated External Termination Block (Euro Style connectors)
133924-01	TC Isolated External Termination Block (Terminal Strip connectors)
133932-01	TC Isolated External Termination Block (Euro Style connectors)
00580442	Connector Header, Internal Termination, 9-position, Green
00580443	Connector Header, Internal Termination, 12-position, Green
00502133	Connector Header, Internal Termination, 12-position, Blue
00580444	Connector Header, Internal Termination, 15-position, Green
134542	3500/60 & 3500/61 User Guide
163179-01	3500/60 Temperature Monitor (without recorders)
133827-01	3500/60 RTD/TC Non-Isolated I/O Module, External Terminations
133819-01	3500/60 RTD/TC Non-Isolated I/O Module, Internal Terminations
133835-01	3500/60 TC Isolated I/O Module, Internal Terminations
133843-01	3500/60 TC Isolated I/O Module, External Terminations
136711-01	3500/60 RTD/TC I/O Module with Internal Barriers and Internal Terminations (Non-Isolated)
163179-02	3500/61 Temperature Monitor (with recorders)
133819-02	3500/61 RTD/TC Non-Isolated I/O Module, Internal Terminations
133827-02	3500/61 RTD/TC Non-Isolated I/O Module, External Terminations
133835-02	3500/61 TC Isolated I/O Module, Internal Terminations
133843-02	3500/61 TC Isolated I/O Module, External Terminations
133892-01	3500/61 Recorder Output External Termination Block (Terminal Strip connectors)
133900-01	3500/61 Recorder Output External Termination Block (Euro Style connectors)
136711-02	3500/61 RTD/TC I/O Module with Internal Barriers and Internal Terminations (Non-Isolated)
