Product Name: 3300 NSv Proximity Probe
Brand Name: Bently Nevada
Model Number: 330910-14-19-10-02-00
Place of Origin: United States
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
overview
| Product Name | 3300 NSv Proximity Probe |
| Brand Name | Bently Nevada |
| Model Number | 330910-14-19-10-02-00 |
| Place of Origin | USA |
| Warranty | 12 months |
| Payment Methods | T/T |
| Shipment | DHL/UPS/EMS/Fedex... |
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
| Product Name | BENTLY NEVADA 330910-14-19-10-02-00 3300 NSv Proximity Probe |
| Manufacturer | BENTLY NEVADA |
| Product Type | 3300 NSv Proximity Probe |
| Part Number | 330910-14-19-10-02-00 |
| Dimensions | 1.8x1.6x110cm |
| Weight | 0.14kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Condition | New & Original in Factory Packing |
| Linear range | 1.5 mm (60 mils) |
| Incremental Scale Factor (ISF) | 7.87 V/mm (200 mV/mil) |
| Effective operating range | 0.25 mm to 1.75 mm target distance |
| Frequency response | 0 to 10 kHz (+0, -3 dB) |
| Deviation from Straight Line (DSL) | < ±0.06 mm (±2.3 mils) |
| Operating temperature | -52°C to +177°C (-62°F to +351°F) |
| Probe material | AISI 304 stainless steel body |
| Tip material | PPS (Polyphenylene Sulfide) for high durability |
| Probe DC resistance | 4.2 ± 0.5 Ω |
| Extension cable center conductor resistance | 0.220 Ω/m |
| Shield resistance | 0.066 Ω/m |
The BENTLY NEVADA 330910-14-19-10-02-00 3300 NSv Proximity Probe is a high-precision vibration and displacement sensing device designed for industrial machinery monitoring. As part of the 3300 NSv series, it provides reliable non-contact measurement of shaft vibration and position, making it suitable for critical rotating equipment such as compressors, turbines, and motors. Manufactured by Bently Nevada (USA), it is supplied in new original factory packaging for high reliability in demanding environments.
The BENTLY NEVADA 330910-14-19-10-02-00 3300 NSv Proximity Probe features a linear range of 1.5 mm (60 mils) with a sensitivity of 7.87 V/mm (200 mV/mil ISF), and an effective operating range from 0.25 mm to 1.75 mm for precise proximity measurement. It provides a frequency response of 0 to 10 kHz (-3 dB) and maintains high measurement accuracy with a deviation from straight line (DSL) of less than ±0.06 mm (±2.3 mils). The probe is constructed with an AISI 304 stainless steel body and a PPS tip for enhanced chemical and thermal resistance, ensuring durability in harsh environments. It operates reliably within a wide temperature range of -52°C to +177°C and has a probe DC resistance of 4.2 ± 0.5 Ω. Additionally, the BENTLY NEVADA 330910-14-19-10-02-00 is fully compatible with long extension cable systems, supporting flexible installation in complex industrial setups.
The BENTLY NEVADA 330910-14-19-10-02-00 3300 NSv Proximity Probe delivers highly accurate and stable vibration measurements, enabling early detection of mechanical issues such as imbalance, misalignment, and shaft displacement. Its rugged stainless-steel construction and PPS tip ensure excellent durability in corrosive and high-temperature environments. The probe offers strong signal stability, wide frequency response, and high measurement precision, making it ideal for critical asset protection. It is also mechanically interchangeable with earlier 3300 RAM probes, simplifying system upgrades.
The BENTLY NEVADA 330910-14-19-10-02-00 3300 NSv Proximity Probe is engineered for harsh industrial environments. It operates reliably in extreme temperatures ranging from -52°C to +177°C, making it suitable for both cold and high-heat applications. Its corrosion-resistant materials allow use in chemically aggressive environments such as process compressors and petrochemical facilities. The probe is designed to maintain stable performance under continuous vibration, high pressure, and long-distance signal transmission conditions.
Q1: Is the BENTLY NEVADA 330910-14-19-10-02-00 3300 NSv Proximity Probe compatible with older 3300 systems?
A: Yes, the BENTLY NEVADA 330910-14-19-10-02-00 3300 NSv Proximity Probe is mechanically and electrically interchangeable with older 3300 RAM probes.
Q2: What makes the 330910-14-19-10-02-00 Probe more durable than standard probes?
A: The 330910-14-19-10-02-00 3300 NSv Proximity Probe uses an AISI 304 stainless steel body and a PPS tip, providing enhanced resistance to corrosion and harsh process conditions.
Q3: Can the 330910-14-19-10-02-00 3300 NSv Proximity Probe be used in high-temperature environments?
A: Yes, the BENTLY NEVADA 330910-14-19-10-02-00 Probe operates reliably in temperatures from -52°C to +177°C.
Q4: Is long-distance signal transmission supported by the BENTLY NEVADA 330910-14-19-10-02-00 NSv Proximity Probe?
A: Yes, the 330910-14-19-10-02-00 3300 NSv Proximity Probe supports long extension cable runs, making it suitable for large industrial installations.
