Bently Nevada 330102-22-58-10-02-00 3300 XL 8 mm Proximity Probes In stock

Bently Nevada 330102-22-58-10-02-00 3300 XL 8 mm Proximity Probes In stock

Product Name:3300 XL 8 mm Proximity Probes

Brand Name:BENTLY NEVADA

Model Number:330102-22-58-10-02-00

Country of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

bently nevada 330102 22 58 10 02 00 3300 xl 8 mm proximity probes in stock-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Bently Nevada
Model Number:	330102-22-58-10-02-00
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Description
Model	330102-22-58-10-02-00
Product Type	3300 XL 8 mm proximity probe (armored)
Thread Type	3/8-24 UNF
Probe Diameter	8 mm
Total Cable Length	0.5 m – 9.0 m options
Linear Range	Approx. 2.0 mm (80 mil)
Output Type	Eddy current displacement signal
Operating Temp	-52°C to +177°C
Dimension (Probe Body)	1.5x113x1.4cm
Thread Engagement	0.563 in max (standard limit)
Weight	0.14kg

Description

Bently Nevada 330102-22-58-10-02-00 is a high-performance 3300 XL 8 mm proximity probe designed for precise vibration and position measurement in industrial rotating machinery. As part of the 3300 XL 8 mm Proximity Transducer System, it works with compatible extension cables and Proximitor sensors to deliver stable, accurate signal output for condition monitoring and protection applications.

The 330102 series features a rugged armored probe design with a 3/8-24 UNF threaded body, providing enhanced mechanical strength and installation reliability in harsh environments. Its eddy current sensing technology ensures accurate non-contact measurement of shaft displacement, even under high vibration and temperature conditions.

With ClickLoc connector compatibility and industrial-grade shielding, 330102-22-58-10-02-00 supports long-term stable operation in power generation, petrochemical, and heavy machinery systems, reducing downtime while improving predictive maintenance efficiency.

Applications

Power plants: Used for generator set status monitoring and relay protection.
Substations: Enable bus differential control, line protection, and switchyard signal acquisition.
Chemical plants: Support process automation and intrinsically safe monitoring.
Steel mills: Ensure stable operation under high temperature and EMI environments.
Machinery manufacturing: Used in automated production lines and robotics control systems.

Features

Armored probe construction for high mechanical durability
ClickLoc connector system for fast, secure installation
High resistance to EMI/RFI interference
Stable performance under extreme temperature conditions
Fully compatible with 3300 XL system components

Functions

Non-contact vibration measurement of rotating shafts
Axial and radial displacement monitoring
Machine condition monitoring for predictive maintenance
Overspeed and Keyphasor reference signal support
Real-time machinery protection and diagnostics

FAQ

Q1: What is 330102-22-58-10-02-00 used for?
A1: It is used for vibration and position monitoring in rotating machinery within the 3300 XL proximity transducer system.

Q2: Is the 330102 probe suitable for harsh environments?
A2: Yes, it features an armored design and industrial-grade materials for high-temperature and high-vibration conditions.

Q3: What system is compatible with this probe?
A3: It is compatible with Bently Nevada 3300 XL extension cables and Proximitor sensors.

Q4: Does it support long-distance cable configurations?
A4: Yes, it supports system lengths from 0.5 m up to 9 m depending on configuration.

Q5: Can it be used for predictive maintenance?
A5: Yes, it provides accurate vibration data for condition monitoring and predictive maintenance systems.

Spares

Number	Describe
03200006	Silicone self-fusing tape, 9.1-meter (10-yard) roll designed for connector protection, providing electrical insulation and environmental sealing. Not recommended for use inside machine casing.
40113-02	Connector Protector Kit for 3300 XL 8 mm probes and extension cables, includes connector protectors and installation tools for field use.
136536-01	Connector protector adapter enabling compatibility between pre-1998 installation tools and 75Ω ClickLoc connector systems.
40180-02	Connector protectors package containing 10 pairs for 3300 XL 8 mm probes and extension cables, used for environmental connector protection.
03839410	75Ω triaxial male connector protector designed for extension cable side, connects with female protector for environmental sealing.
03839420	75Ω triaxial female connector protector for probe lead, attaches to male protector and shields connections from environmental exposure.
04301007	3/8-24 probe lock nut with dual safety wire holes for secure mechanical fixation and vibration-resistant installation.
04301008	M10 x 1 probe lock nut with safety wire holes, designed to secure probe installation with additional locking wire support.
330153-01	3300 XL connector kit including male/female ClickLoc connectors, color-coded sleeves, slit FEP tubing, and silicone tape for installation.
330153-09	3300 XL ETR connector kit for extended temperature applications, includes ClickLoc connectors, high-temperature FEP tubing, and sealing tape.
163356	Connector crimp tool kit with multi-connector inserts and installation instructions, compatible with 330153 kits and ClickLoc systems post-2003.
