Product Name:3300 XL 8 mm Proximity Probes
Brand Name:BENTLY NEVADA
Model Number:330103-00-04-05-02-CN
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330103-00-04-05-02-CN |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Specification |
|
Product Model |
330103-00-04-05-02-CN |
|
Series |
3300 XL 8 mm Proximity Probe |
|
Probe Diameter |
8 mm |
|
Thread Type |
M10 x 1 |
|
Total Length Range |
0.5 m – 9.0 m system options |
|
Output Type |
Eddy current displacement signal |
|
Weight |
0.06kg |
|
Extension Cable Weight |
~34 g/m |
|
Operating Temperature |
-52°C to +177°C |
|
Cable Type |
75Ω triaxial shielded cable |
|
Dimension |
1.8x68.4x1.6cm |
The 330103-00-04-05-02-CN is a high-performance eddy current proximity probe designed within the 3300 XL 8 mm series for precise vibration and position monitoring in industrial machinery. It works as part of a complete system with a matching extension cable and Proximitor sensor, delivering stable, non-contact measurement of shaft displacement in rotating equipment.
Built for demanding environments, the 330103-00-04-05-02-CN features a rugged stainless-steel probe body and advanced TipLoc/CableLoc structural design to enhance mechanical strength and signal reliability. It supports both static and dynamic measurement tasks, making it ideal for critical asset protection and condition monitoring applications.
When integrated into the 3300 XL 8 mm system, the probe ensures accurate signal output, excellent interchangeability, and API-compliant performance. It is widely used in turbines, compressors, and heavy rotating equipment where long-term stability and measurement precision are essential.
Q1: What is the 330103-00-04-05-02-CN used for?
A1: It is used for vibration and position measurement in rotating machinery such as turbines and compressors.
Q2: Can it work with other 3300 XL components?
A2: Yes, it is fully compatible with 3300 XL extension cables and Proximitor sensors.
Q3: What industries commonly use this probe?
A3: It is widely used in power plants, petrochemical plants, steel mills, and manufacturing systems.
Q4: What type of signal does it provide?
A4: It delivers an eddy current-based analog signal proportional to shaft displacement.
Q5: Is it suitable for harsh environments?
A5: Yes, it is designed for high temperature, vibration, and industrial EMI conditions.
| Number | Describe |
|---|---|
| 141078 | 3300 XL 8 mm and 3300 5 mm Proximity Transducer System Manual |
| 175751 | 3300 XL Multi-Purpose Stainless Steel Housing, 12”x12”x6”, supports up to 8 Proximitor Sensors (DIN mount) or 6 (panel mount), ATEX Zone 0/1 certified |
| 176467 | 3300 XL Multi-Purpose Stainless Steel Housing, 12”x8”x6”, supports up to 4 Proximitor Sensors in DIN or panel mount configurations, ATEX certified |
| 330181 | 3300 XL Multi-Purpose Stainless Steel Housing, 13”x9.5”x7”, supports up to 8 sensors (DIN) or 6 (panel), hazardous area approved (ATEX Zone 0/1, North American Division 1/2) |
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire, cut-to-length field wiring solution |
| 138492-01 | Replacement panel-mount mounting pad for Proximitor sensor installation |
| 138493-01 | Replacement DIN-mount mounting pad for Proximitor sensor installation |
| 148722-01 | 3300 XL test plug with 3-pin adapter and color-coded leads for Proximitor sensor field performance testing |
| 04310310 | 3300 XL Proximitor sensor panel-mount screw, 6-32 UNC thread forming type, 4 screws required per sensor |
| 03200006 | Silicone self-fusing tape, 9.1-meter roll, used for connector insulation and environmental protection |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables, includes installation tools and protectors |
| 136536-01 | Connector protector adapter for compatibility with pre-1998 installation tools and 75Ω ClickLoc connectors |
