Bently Nevada 330103-00-05-15-02-CN 3300 XL 8 mm Proximity Probes Ready For Ship

Bently Nevada 330103-00-05-15-02-CN 3300 XL 8 mm Proximity Probes Ready For Ship

Product Name:3300 XL 8 mm Proximity Probes

Brand Name:BENTLY NEVADA

Model Number:330103-00-05-15-02-CN

Country of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

bently nevada 330103 00 05 15 02 cn 3300 xl 8 mm proximity probes ready for ship-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Bently Nevada
Model Number:	330103-00-05-15-02-CN
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	330103-00-05-15-02-CN
Product Type	3300 XL 8 mm Proximity Probe
Thread Type	M10 × 1 Metric Thread
Armor Option	Without Armor
Total Length	1.5 meters (4.9 ft)
Connector Type	Miniature coaxial ClickLoc connector
Cable Type	Standard cable
Linear Range	2 mm (80 mils)
Sensitivity	7.87 V/mm (200 mV/mil)
Frequency Response	0 to 10 kHz
Probe Material	Polyphenylene Sulfide (PPS)
Case Material	AISI 303/304 Stainless Steel
Operating Temperature	-52°C to +177°C
Protection Compliance	API 670 Compatible
Dimension	23x1.6x20.5cm
Approximate Weight	0.08kg
Certification	CSA, ATEX, IECEx available

Description

Bently Nevada 330103-00-05-15-02-CN is a high-performance eddy current proximity probe designed for continuous shaft vibration, position, and speed monitoring in demanding industrial environments. As part of the 3300 XL 8 mm Proximity Transducer System, this model delivers stable signal output, excellent linearity, and strong resistance to electromagnetic interference, making it suitable for rotating machinery protection systems.

The 330103-00-05-15-02-CN probe features an M10 × 1 threaded stainless-steel case, miniature coaxial ClickLoc connector, and durable standard cable construction. Together with compatible 3300 XL Proximitor Sensors and extension cables, the system supports accurate dynamic and static measurements for turbines, compressors, pumps, motors, and generators operating in power generation, petrochemical, and heavy industrial facilities.

Compared with earlier non-XL transducer systems, the 3300 XL 8 mm series provides improved RFI/EMI immunity, enhanced mechanical durability, simplified installation, and full API 670 compliance. The modular design also ensures backward compatibility with existing 3300 series 5 mm and 8 mm monitoring components, helping reduce maintenance complexity and upgrade costs.

Applications

Power plants: Used for turbine vibration monitoring and generator protection systems.
Oil & gas facilities: Applied in compressors, pumps, and rotating machinery condition monitoring.
Chemical plants: Supports process automation and hazardous-area vibration monitoring.
Steel mills: Provides reliable monitoring for motors and heavy industrial equipment.
Machinery manufacturing plants: Used in automated production lines, robotic systems, and industrial machinery monitoring.

Features

API 670 compliant monitoring performance
High resistance to EMI and RFI interference
Rugged stainless-steel probe construction
ClickLoc connector for secure installation
Backward compatible with 3300 series systems
Excellent vibration and position measurement accuracy
Optional hazardous-area certifications available
Reliable operation in harsh industrial environments

Functions

Measures shaft vibration and displacement
Detects axial and radial shaft movement
Provides Keyphasor reference signals
Supports machinery protection systems
Enables predictive maintenance monitoring
Delivers real-time condition feedback
Improves rotating equipment reliability

FAQ

Q1: What is the main function of the 330103-00-05-15-02-CN probe?
A1: It is used for non-contact vibration and position monitoring of rotating machinery.

Q2: Is the 330103-00-05-15-02-CN compatible with older 3300 systems?
A2: Yes, it is backward compatible with many non-XL 3300 series 5 mm and 8 mm components.

Q3: What industries commonly use this proximity probe?
A3: Power generation, oil & gas, chemical processing, steel manufacturing, and industrial automation industries widely use it.

Q4: What connector type does this model use?
A4: It uses a miniature coaxial ClickLoc connector for secure and easy installation.

Q5: Does the 330103-00-05-15-02-CN support hazardous-area applications?
A5: Yes, optional CSA, ATEX, and IECEx approvals are available for hazardous industrial environments.

Spares

Number	Description
148722-01	3300 XL test plug with 3 color-coded 1-meter wires and banana plugs for checking Proximitor sensor performance without removing field wiring.
04310310	3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread forming mounting screw; four screws required per sensor.
03200006	Silicone self-fusing tape, 9.1-meter roll for connector insulation and environmental protection.
40113-02	Connector Protector Kit for 3300 XL 8 mm probes and extension cables, including protectors and installation tools.
136536-01	Connector protector adapter for compatibility with pre-1998 installation tools and 75Ω ClickLoc connectors.
40180-02	Package of 10 pairs of connector protectors for 3300 XL 8 mm probes and extension cables.
03839410	75Ω triaxial male connector protector for environmental protection of extension cable connections.
03839420	75Ω triaxial female connector protector for protecting probe lead and Proximitor sensor connections.
04301007	3/8-24 probe lock nut with safety wire holes for secure probe installation.
04301008	M10 × 1 probe lock nut with safety wire holes for secure probe installation.
330153-01	3300 XL connector kit including male/female ClickLoc connectors, sleeves, FEP tubing, and silicone tape.
