Bently Nevada 330103-00-05-20-02-CN 3300 XL 8 mm Proximity Probes Original new

Bently Nevada 330103-00-05-20-02-CN 3300 XL 8 mm Proximity Probes Original new

Product Name:3300 XL 8 mm Proximity Probes

Brand Name:Bently Nevada

Model Number:330103-00-05-20-02-CN

Country of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

bently nevada 330103 00 05 20 02 cn 3300 xl 8 mm proximity probes original new-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Bently Nevada
Model Number:	330103-00-05-20-02-CN
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Details
Product Model	330103-00-05-20-02-CN
Series	3300 XL 8 mm Proximity Probe
Thread Type	M10 x 1
Probe Type	Non-armor configuration
Measurement Principle	Eddy current displacement sensing
Output Type	Analog voltage proportional signal
Operating Temperature	-52°C to +177°C
Frequency Response	0 to 10 kHz
Cable Type	75Ω triaxial cable
Connector Type	ClickLoc gold-plated connector
Linear Range	Up to 2 mm
Material	Stainless steel probe body (AISI grade)
Weight	0.1kg
Dimensions	21x18x1.8cm

Description

330103-00-05-20-02-CN is part of the Bently Nevada 3300 XL 8 mm proximity probe series, engineered for high-precision vibration and position monitoring in industrial rotating machinery. The system is designed to work with compatible extension cables and Proximitor sensors, delivering stable and accurate eddy current measurement performance in demanding environments.

The 3300 XL 8 mm probe family (including 330103 and 330104 variants) provides excellent interchangeability, reducing calibration complexity and improving maintenance efficiency. Its robust construction ensures reliable operation in turbines, compressors, and fluid-film bearing machines.

With advanced EMI/RFI immunity and a durable stainless-steel probe body, the system supports long-distance signal stability and compliance with API 670 standards, making it suitable for critical condition monitoring applications in modern industrial automation systems.

Applications

Power Plants: Generator vibration monitoring and turbine protection systems
Substations: Relay protection, bus monitoring, and switching system diagnostics
Chemical Plants: Process automation and intrinsically safe signal measurement
Steel Mills: High-temperature machinery monitoring under EMI-heavy environments
Manufacturing Plants: Automated production lines, robotics, and equipment control systems

Features

High-accuracy eddy current displacement measurement
API 670 compliant performance standard
Robust stainless-steel construction for harsh environments
ClickLoc connector for fast and secure installation
High immunity to EMI and RF interference
Fully interchangeable with 3300 XL system components

Functions

Measures shaft vibration in rotating machinery
Detects axial position and displacement changes
Supports speed and Keyphasor reference signals
Enables real-time condition monitoring
Provides stable output for predictive maintenance systems

FAQ

Q1: What is the 330103-00-05-20-02-CN used for?
A1: It is used for measuring vibration and position in industrial rotating machinery such as turbines and compressors.

Q2: Is it compatible with other 3300 XL components?
A2: Yes, it is fully compatible with 3300 XL extension cables and Proximitor sensors.

Q3: What industries use this probe?
A3: It is widely used in power generation, petrochemical, steel, and manufacturing industries.

Q4: What measurement technology does it use?
A4: It uses eddy current technology for non-contact displacement measurement.

Q5: Does it support high-temperature environments?
A5: Yes, it operates reliably up to +177°C depending on system configuration.

Spares

Number	Describe
148722-01	3300 XL test plug with 3-pin design and color-coded 1-meter wires terminated in banana plugs, used for checking Proximitor sensor performance through terminal test holes without removing field wiring.
04310310	3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread forming type, used for secure mounting of Proximitor sensors (4 screws required per unit).
03200006	Silicone self-fusing tape, 9.1-meter roll designed for electrical insulation and environmental protection of connectors; not recommended for internal machine casing use.
40113-02	Connector Protector Kit for 3300 XL 8 mm probes and extension cables, including installation tools and protective components for secure connector sealing.
136536-01	Connector protector adapter enabling compatibility with pre-1998 installation tools for 75Ω ClickLoc connector systems.
40180-02	Connector protectors package containing 10 pairs designed to provide environmental sealing and protection for probe and extension cable connectors.
03839410	75Ω triaxial male connector protector designed for extension cable side, ensuring environmental sealing when connected to probe-side female protector.
03839420	75Ω triaxial female connector protector used on probe leads or extension cables to protect connections and prevent environmental contamination.
04301007	3/8-24 probe lock nut with dual safety wire holes, designed for secure mechanical fixation of proximity probes in industrial applications.
04301008	M10 x 1 probe lock nut with safety wire holes, used to secure probe installation and prevent loosening under vibration conditions.
