Product Name:3300 XL 8 mm Proximity Probes
Brand Name:Bently Nevada
Model Number:330103-00-05-90-12-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330103-00-05-90-12-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Model Number | 330103-00-05-90-12-00 |
| Product Type | 3300 XL 8 mm Proximity Probe |
| Measurement Principle | Eddy Current Technology |
| Thread Type | M10 × 1 Metric Thread |
| Probe Diameter | 8 mm |
| Unthreaded Length | 50 mm |
| Total System Length | 9.0 m (29.5 ft) |
| Cable Type | FluidLoc Cable |
| Connector Type | Miniature Coaxial ClickLoc Connector |
| Probe Case Material | AISI 303/304 Stainless Steel |
| Probe Tip Material | Polyphenylene Sulfide (PPS) |
| Linear Range | 2 mm (80 mils) |
| Scale Factor | 7.87 V/mm (200 mV/mil) |
| Operating Temperature | -52°C to +177°C |
| Tensile Strength | 330 N (75 lbf) |
| Weight | Approx. 0.32 kg probe; typical system weight 0.7 kg |
| Dimension | 8 mm diameter probe, M10 × 1 thread, 50 mm unthreaded length, 9 m cable |
The 330103-00-05-90-12-00 is a precision-engineered proximity probe from the proven Bently Nevada 3300 XL 8 mm monitoring platform. Designed for non-contact measurement of shaft vibration, axial position, and dynamic displacement, this probe delivers reliable condition monitoring for critical rotating equipment operating in demanding industrial environments.
Built with an M10 × 1 metric threaded housing and a durable FluidLoc cable design, the 330103-00-05-90-12-00 helps prevent fluid migration through the cable assembly while maintaining stable signal transmission. Its advanced eddy-current sensing technology ensures accurate detection of conductive targets, making it suitable for both continuous monitoring and machinery protection applications.
When paired with compatible 3300 XL Proximitor Sensors and extension system components, the 330103-00-05-90-12-00 forms a complete vibration and position measurement solution. It is widely deployed on turbines, compressors, pumps, motors, and generators where dependable performance, long-term stability, and predictive maintenance capabilities are essential.
Power Plants: Turbine shaft vibration monitoring, generator rotor position measurement, overspeed protection systems, and machinery protection diagnostics.
Oil & Gas Facilities: Gas turbine condition monitoring, compressor vibration analysis, pump shaft displacement measurement, and critical rotating asset protection.
Petrochemical Plants: Process equipment health monitoring, high-temperature rotating machinery supervision, and predictive maintenance program support.
Steel Mills: Monitoring of large motors and rolling equipment, vibration detection in high-temperature and high-EMI environments, and continuous machinery reliability assessment.
Water & Hydropower Stations: Hydro turbine shaft position monitoring, generator condition analysis, and early fault detection for rotating assets.
Machinery Manufacturing Plants: Rotating equipment testing, dynamic vibration measurement, industrial automation monitoring, and production line performance optimization.
Q1: What is the primary purpose of the 330103-00-05-90-12-00?
A1: It is used to measure shaft vibration, position, and displacement in rotating machinery without physical contact.
Q2: What advantage does the FluidLoc cable provide?
A2: FluidLoc technology helps prevent oil and fluid migration through the cable, improving system reliability.
Q3: Is the 330103-00-05-90-12-00 compatible with 3300 XL systems?
A3: Yes, it is designed to operate with compatible 3300 XL Proximitor Sensors and associated system components.
Q4: Which industries commonly use this proximity probe?
A4: Power generation, oil and gas, petrochemical, steel manufacturing, and industrial automation sectors frequently use this model.
Q5: What sensing technology is used in this probe?
A5: The probe utilizes eddy-current sensing technology for precise non-contact measurement of conductive targets.
|
Number |
Description |
|
141078 |
3300 XL 8 mm and 3300 5 mm Proximity Transducer System Manual. |
|
175751 |
3300 XL Multi-Purpose Stainless Steel Housing, 12” × 12” × 6”. Supports up to 8 Proximitor Sensors in DIN-mount configuration or 6 sensors in panel-mount configuration. Available with ATEX Zone 0 and Zone 1 certifications. |
|
176467 |
3300 XL Multi-Purpose Stainless Steel Housing, 12” × 8” × 6”. Supports up to 4 3300 XL Proximitor Sensors in both DIN-mount and panel-mount configurations. Available with ATEX Zone 0 and Zone 1 certifications. |
|
330181 |
3300 XL Multi-Purpose Stainless Steel Housing, 13” × 9.5” × 7”. Supports up to 8 Proximitor Sensors in DIN-mount configuration or 6 sensors in panel-mount configuration. Available with ATEX Zone 0, Zone 1, North American Division 1 and Division 2 certifications. |
|
02120015 |
Bulk field wire, 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire. Length specified in feet. |
|
138492-01 |
Replacement panel-mount mounting pad. |
|
138493-01 |
Replacement DIN-mount mounting pad. |
|
148722-01 |
3300 XL Test Plug with three color-coded 1-meter leads and banana plugs. Used for testing Proximitor Sensor performance without disconnecting field wiring. |
|
04310310 |
3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread-forming type. Four screws required per sensor. |
|
03200006 |
Silicone self-fusing tape, 9.1 m (10 yd) roll, providing electrical insulation and environmental protection for connectors. |
|
40113-02 |
Connector Protector Kit for 3300 XL 8 mm probes and extension cables, including connector protectors and installation tools. |
|
136536-01 |
Connector protector adapter for compatibility with pre-1998 installation tools used on 75Ω ClickLoc connectors. |
|
40180-02 |
Package containing 10 pairs of connector protectors for 3300 XL 8 mm probes and extension cables. |
|
03839410 |
75Ω triaxial male connector protector for environmental protection of probe and extension cable connections. |
|
03839420 |
75Ω triaxial female connector protector for environmental protection of probe, extension cable, and Proximitor Sensor connections. |
