Bently Nevada 330103-00-15-05-01-00 3300 XL 8 mm Proximity Probes In stock

Bently Nevada 330103-00-15-05-01-00 3300 XL 8 mm Proximity Probes In stock

Product Name:3300 XL 8 mm Proximity Probes

Brand Name:BENTLY NEVADA

Model Number:330103-00-15-05-01-00

Country of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

bently nevada 330103 00 15 05 01 00 3300 xl 8 mm proximity probes in stock-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Bently Nevada
Model Number:	330103-00-15-05-01-00
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Specification Item	Details
Product Model	330103-00-15-05-01-00
Product Type	3300 XL 8 mm Proximity Probe
Thread Type	M10 × 1 Metric Thread
Unthreaded Length	0 mm
Overall Case Length	150 mm
Total Length	0.5 meter (1.6 ft)
Connector Type	Miniature coaxial ClickLoc connector with protector
Probe Diameter	8 mm
Frequency Response	0 to 10 kHz
Linear Range	2 mm (80 mils)
Output Sensitivity	7.87 V/mm (200 mV/mil)
Probe Material	AISI 303/304 Stainless Steel
Cable Type	75 Ω triaxial FEP insulated cable
Operating Temperature	-52°C to +177°C
Protection Rating	EMI/RFI resistant design
Dimension	2x1.6x58cm
Weight	0.1kg
Certifications	CE, ATEX, IECEx, RoHS, SIL 2/SIL 3

Description

TheBently NevadaBently Nevada330103-00-15-05-01-00belongs to the advanced3300 XL 8 mm Proximity Transducer System, designed for high-accuracy shaft vibration and position monitoring in industrial rotating machinery. This proximity probe delivers reliable non-contact measurement performance for turbines, compressors, motors, and fluid-film bearing equipment operating in demanding environments.

Engineered with durable stainless-steel construction and gold-plated ClickLoc connectors, the330103-00-15-05-01-00provides stable signal transmission, strong EMI/RFI resistance, and simplified installation. The system supports dynamic vibration measurement, axial position detection, Keyphasor reference applications, and speed monitoring across critical industrial assets.

Compared with earlier proximity sensor generations, the3300 XL Seriesoffers enhanced interchangeability, improved environmental protection, and optimized temperature stability. Its compact M10 × 1 threaded probe structure makes it suitable for high-density installations where long-term reliability and precise machinery diagnostics are essential.

Applications

Power plants: Used for turbine shaft vibration monitoring and generator rotor position detection.
Oil & gas facilities: Supports centrifugal compressor and pump condition monitoring systems.
Chemical plants: Integrates with DCS and machinery protection systems for hazardous-area vibration measurement.
Steel mills (metallurgical plants): Performs stable proximity sensing under high temperature and strong electromagnetic interference conditions.
Machinery manufacturing plants: Applied in rotating equipment diagnostics, balancing systems, and automated production lines.
Marine and offshore platforms: Enables vibration and shaft displacement monitoring in ship propulsion systems.
Paper mills and water treatment plants: Used for motor, fan, and pump predictive maintenance applications.

Features

Non-contact eddy current measurement technology
Compact M10 × 1 threaded probe structure
High EMI/RFI immunity performance
Gold-plated ClickLoc connector system
Excellent temperature stability
Rugged stainless-steel probe housing
API 670 compliant performance
Backward compatible with 3300 Series systems

Functions

Measures shaft vibration and displacement
Detects axial position movement
Supports Keyphasor speed reference applications
Enables predictive maintenance monitoring
Provides continuous machinery condition feedback
Improves rotating equipment protection accuracy
Supports high-speed industrial diagnostics systems

FAQ

Q1:What is the primary function of the330103-00-15-05-01-00?
A1:It provides non-contact vibration and shaft position measurement for rotating machinery monitoring systems.

Q2:Is the330103-00-15-05-01-00compatible with older 3300 systems?
A2:Yes, the 3300 XL series is backward compatible with many non-XL 3300 5 mm and 8 mm components.

Q3:What industries commonly use this proximity probe?
A3:Power generation, oil & gas, steel manufacturing, marine, and industrial automation industries widely use this probe.

Q4:Does the probe support hazardous-area installations?
A4:Yes, it supports ATEX, IECEx, and CSA hazardous-area approvals.

Q5:What connector type is used in the330103-00-15-05-01-00?
A5:The probe uses a miniature coaxial ClickLoc connector with connector protector for secure installation.

Spares

Number	Describe
148722-01	3300 XL test plug with 3 color-coded 1-meter wires and banana plugs for Proximitor sensor performance testing
04310310	3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread forming mounting screw
03200006	Silicone self-fusing tape for connector insulation and environmental protection
40113-02	Connector Protector Kit for 3300 XL 8 mm probes and extension cables with installation tools
136536-01	Connector protector adapter for pre-1998 installation tools and 75Ω ClickLoc connectors
40180-02	Connector protectors package containing 10 pairs for 3300 XL 8 mm probes and extension cables
03839410	75Ω triaxial male connector protector for environmental protection of extension cable connections
03839420	75Ω triaxial female connector protector for probe lead and Proximitor sensor connection protection
04301007	3/8-24 probe lock nut with safety wire holes for secure probe mounting
04301008	M10 × 1 probe lock nut with safety wire holes for secure installation
330153-01	3300 XL connector kit with male/female ClickLoc connectors, sleeves, FEP tubing, and silicone tape
